Menu Options
Copy Mode
Note:
❏ Available menus vary depending on the layout you selected.
❏ Press Settings to display hidden setting menus.
Menu Settings and Explanations
Number of copies Enter the number of copies.
Layout With Border Copies with a border around the edges.
2-up Copies multiple page originals onto one sheet.
When placing originals in the ADF, insert them into the feeder from the top or
left edge.
Load vertical originals as shown below, and select Portrait from Document
Orientation.
Load vertical originals as shown below, and select Landscape from
Document Orientation.
4-up
ID Card Scans both sides of an ID card and copies onto one side of A4 size paper.
Document Size Select the size of your original.
Zoom Enlarges or reduces the original.
Select Auto Fit Page to t to the paper size of the selected paper source.
Paper Source Select the paper source that you want to use.
Feeds paper automatically using the Paper Setup settings made when you loaded the paper.
Select the paper size and paper type you loaded when Rear Paper Feed is selected.
2-Sided Select 2-sided layout.
Select a layout, press Advanced, and then select the binding position of your original and the paper.
Document
Orientation
Select the orientation of your original.
Quality Select the type of your original.
Text: Provides faster printing, but the printouts may be faint.
Photo: Provides higher quality printing, but the printing speed may be slower.
Density Set the density of your copies.
User's Guide
Printer Basics
22
