Photoelectric Device CIS
Eective Pixels 10200 × 14040 pixels at 1200 dpi
Maximum Document Size 216 × 297 mm (8.5 × 11.7 in.)
A4, Letter
Scanning Resolution 1200 dpi (main scan)
2400 dpi (sub scan)
Output Resolution 50 to 4800, 7200, 9600 dpi
(50 to 4800 dpi in 1 dpi increments.)
Color Depth Color
❏ 16 bits per pixel per color internal
❏ 8 bits per pixel per color external
Black and white
❏ 16 bits per pixel per color internal
❏ 1 or 8 bits per pixel per color external
Light Source LED
Interface Specications
For Computer Hi-Speed USB
For External USB Device Hi-Speed USB
Fax
Specications
Fax Type ITU-T Super Group 3, Black-and-white and color fax capability (Black-and-white
only for receiving faxes)
Supported Lines Standard analogue telephone lines, PBX (Private Branch Exchange) telephone
systems
Speed Up to 33.6 kbps
Resolution Monochrome
❏ Standard: 8 pel/mm × 3.85 line/mm (203 pel/in. × 98 line/in.)
❏ Fine: 8 pel/mm × 7.7 line/mm (203 pel/in. × 196 line/in.)
❏ Super Fine: 8 pel/mm × 15.4 line/mm (203 pel/in. × 392 line/in.)
❏ Ultra Fine: 16 pel/mm × 15.4 line/mm (406 pel/in. × 392 line/in.)
❏ Photo: 8 pel/mm × 7.7 line/mm (203 pel/in. × 196 line/in.)
Color
❏ Fine: 200 × 200 dpi
❏ Photo: 200 × 200 dpi
Page Memory Up to 550 pages (when received ITU-T No.1 chart in monochrome draft mode)
User's Guide
Appendix
167
