7. Uninstall the optional paper cassette if it is installed.
8. Pack the printer in its box, using the protective materials.
Note:
If print quality has declined the next time you print, clean and align the print head.
Related Information
& “Part Names and Functions” on page 16
& “Checking and Cleaning the Print Head” on page 115
& “Aligning the Print Head” on page 117
Accessing an External USB Device From a Computer
You can write or read data on an external USB device such as a USB
ash
drive that has been inserted in the
printer from a computer.
c
Important:
❏ When sharing an external device inserted in the printer between computers connected over USB and over a
network, write access is only allowed to the computers that are connected by the method you selected on the
printer. To write to the external USB device, enter the Setup on the control panel, and then select System
Administration > Printer Settings > Memory Device Interface > File Sharing and a connection method. Data
can be read by computers connected over USB and over a network.
❏ To write to an external USB device connected to the computer over a network, enter the Setup on the control
panel, and then select System Administration > Printer Settings > Memory Device Interface > File Sharing >
Wi - F i / N e t w o r k .
Note:
It takes a while to recognize data from a computer if a large external USB device, such as 2TB HDD, is connected.
Windows
Select an external USB device in Computer or My Computer. e data on the external USB device is displayed.
Note:
If you connected the printer to the network without using the soware disk or Web Installer, map a USB port as a network
drive. Open Run and enter a printer name \\EPSONXXXXX or a printer's IP address \\XXX.XXX.XXX.XXX to Open:.
Right-click a device icon displayed to assign the network. e network drive appears in Computer or My Computer.
Mac OS X
Select a corresponding device icon. e data on the external USB device is displayed.
Note:
❏ To remove an external USB device, drag the device icon to the trash icon. Otherwise, data in the shared drive may not be
displayed correctly when another external USB device is inserted.
❏ If you connected the printer to the network without using EpsonNet Setup, map a USB port as a network drive. Select Go
> Connect to Server. Enter a printer name cifs://EPSONXXXXX or smb://EPSONXXXXX in the Server Address and
click Connect.
Related Information
& “Printer Settings” on page 31
User's Guide
Appendix
182
