Epson WorkForce Pro WF-M5690DWF [139/187] Solving problems
![Epson WorkForce Pro WF-M5690DWF [139/187] Solving problems](/views2/1168438/page139/bg8b.png)
Code Problem Solution
208 The fax could not be sent to some of the specied
recipients.
Print a Fax Log or Last Transmission report for
previous faxes from Fax Report in the Fax mode to
check the failed destination. When the Save Failure
Data setting is enabled, you can resend a fax from
Job Monitor in Status Menu.
301 There is not enough storage space available to save
the data in the memory device.
❏ Increase the storage space in the memory device.
❏ Reduce the number of documents.
❏ Lower the scanning resolution or increase the
compression ratio to reduce the size of the
scanned image.
302 The memory device is write-protected. Disable write protection on the memory device.
303 No folder has been created to save the scanned
image.
Insert another memory device.
304 The memory device has been removed. Reinsert the memory device.
305 An error occurred while saving the data to the
memory device.
If the external device is accessed from a computer,
wait for a while and then try again.
306 The memory is full. Wait until other ongoing jobs are nished.
311 A DNS error has occurred.
❏ Select Setup > System Administration > Wi-Fi/
Network Settings > Advanced Setup > DNS
Server, and then check the DNS settings.
❏ Check the DNS settings for the server, the
computer, or the access point.
312 An authentication error has occurred.
Select Setup > System Administration > Wi-Fi/
Network Settings > Advanced Setup > Email
Server > Server Settings, and then check the server
settings.
313 A communication error has occurred.
❏ Select Setup > System Administration > Wi-Fi/
Network Settings > Advanced Setup > Email
Server > Server Settings to check the email
server settings. You can check the cause of the
error by running connection check.
❏ The authentication method of the settings and
the email server may not match. When you select
O as the authentication method, make sure the
authentication method of the email server is set
to None.
❏
Check the network connection. See the Network
Guide for more details.
314 The data size exceeds the maximum size for attached
les.
❏ Increase the Attached File Max Size setting in
the scan settings.
❏ Lower the scanning resolution or increase the
compression ratio to reduce the size of the
scanned image.
315 The memory is full. Retry after other ongoing jobs are nished.
User's Guide
Solving Problems
139
