Redial
*
2 times (with 1 minute intervals)
Interface RJ-11 Phone Line, RJ-11 Telephone set connection
*The
specications
may
dier
by country or region.
Wi-Fi Specications
Standards IEEE802.11b/g/n
Frequency Range 2.4 GHz
Coordination Modes
Infrastructure, Ad hoc
*1
, Wi-Fi Direct
*2 *3
Wireless Securities
WEP (64/128bit), WPA2-PSK (AES)
*4
, WPA2-Enterprise
*1 Not supported for IEEE 802.11n.
*2 Not supported for IEEE 802.11b.
*3 Simple AP mode is compatible with Ethernet connection.
*4 Complies with WPA2 standards with support for WPA/WPA2 Personal.
Ethernet
Specications
Standards
IEEE802.3i (10BASE-T)
*1
IEEE802.3u (100BASE-TX)
IEEE802.3ab (1000BASE-T)
*1
IEEE802.3az (Energy Ecient Ethernet)
*2
Communication Mode Auto, 10Mbps Full duplex, 10Mbps Half duplex, 100Mbps Full duplex, 100Mbps
Half duplex
Connector RJ-45
*1 Use a category 5e or higher STP (Shielded twisted pair) cable to prevent risk of radio interference.
*2 The connected device should comply with IEEE802.3az standards.
Security Protocol
IEEE802.1X
*
IPsec/IP Filtering
SSL/TLS HTTPS Server/Client
IPPS
SNMPv3
* You need to use a device for connection that complies with IEEE802.1X.
User's Guide
Appendix
168
