Supported Third Party Services
AirPrint Print iOS 5 or later/Mac OS X v10.7.x or later
Google Cloud Print
External USB Device
Specications
Devices Maximum Capacities
MO Drive
*
1.3 GB
Hard Disk Drive
*
USB Flash Drive
2 TB (formatted in FAT, FAT32, or exFAT.)
* We do not recommend using external USB devices that are powered by USB. Use only external USB devices with
independent AC power sources.
You cannot use the following devices:
❏ A device that requires a dedicated driver
❏ A device with security settings (password, encryption, and so on)
❏ A device with a built-in USB hub
Epson cannot guarantee all operations of externally connected devices.
Supported Data
Specications
File Format
JPEG with the Exif Version 2.3 standard taken by digital cameras DCF
*1
version 1.0
or 2.0
*2
compliant
TIFF 6.0 compliant images as below
❏ RGB full color images (not compressed)
❏ Binary images (not compressed or CCITT encoded)
PDF Version 1.7 compliant data le
Image Size Horizontal: 80 to 10200 pixels
Vertical: 80 to 10200 pixels
File Size Up to 2 GB
Maximum Number of Files
JPEG: 9990
*3
TIFF: 999
PDF: 999
*1 Design rule for Camera File system.
*2 Photo data stored on digital cameras with a built-in memory is not supported.
*3 Up to 999 les can be displayed at a time. (If the number of les exceeds 999, the les are displayed in groups.)
User's Guide
Appendix
169
