Menu Settings and Explanations
PCL Menu Font Source Resident: Select to use a preinstalled font on the printer.
Download: Select to use a font you have downloaded.
Font Number Select the default font number for the default font source. The available number
varies depending on the settings you made.
Pitch Set the default font pitch if the font is scalable and of xed-pitch. You can select from
0.44 to 99.99 cpi (characters per inch), in 0.01 increments.
This item may not appear depending on the font source or font number settings.
Height Set the default font height if the font is scalable and proportional. You can select
from 4.00 to 999.75 points, in 0.25 increments.
This item may not appear depending on the font source or font number settings.
Symbol Set Select the default symbol set. If the font that you selected in the font source and the
font number setting is not available in the new symbol set setting, the font source
and the font number settings are automatically replaced with the default value, IBM-
US.
Form Set the number of lines for the selected paper size and orientation. This also causes a
line spacing (VMI) change, and the new VMI value is stored in the printer. This means
that later changes in the page size or orientation settings cause changes in the Form
value based on the stored VMI.
CR Function Select the line feed command when printing with a driver from a specic operating
system.
LF Function
Paper Source
Assign
Set the assignment for the paper source select command. When 4 selected, the
commands are set as compatible with the HP LaserJet 4. When 4K is selected, the
commands are set as compatible with the HP LaserJet 4000, 5000, and 8000. When
5S is selected, the commands are set as compatible with the HP LaserJet 5S.
PS3 Menu Error Sheet Prints a sheet showing the error status when any PostScript errors occur while
printing and any errors occur while printing a PDF le.
Binary Enable this feature when printing data that contains binary images. This settings is
only available when the printer is connected to the network.
The application may send the binary data even if the printer driver setting is set to
ASCII, but you can print the data when this feature is enabled.
PDF Page Size
Select the paper size when printing a PDF le. If Auto is selected, the paper size is
determined based on the size of the rst page that is printed.
Contacts Mode
Menu Description
Menu Registers contacts and a contact group, or prints the contacts list.
View Select whether to display all contacts or the contacts for each feature only.
LDAP allows you to search in the contacts registered in the LDAP server.
User's Guide
Printer Basics
36
