1. Download the executable le of the driver from the Epson support website.
http://www.epson.eu/Support (Europe)
http://support.epson.net/ (outside Europe)
Note:
We recommend downloading the latest driver from the website. However you can get it from the soware disc that came
with the printer. Access to "Driver\Universal".
2. Double-click the executable
le
that you have downloaded from the website or that is in the
soware
disc.
3. Follow the on-screen instructions for the rest of the installation.
Updating Applications and Firmware
You may be able to clear certain problems and improve or add functions by updating the applications and the
rmware. Make sure you use the latest version of the applications and rmware.
1. Make sure that the printer and the computer are connected, and the computer is connected to the internet.
2. Start EPSON
Soware
Updater, and update the applications or the
rmware.
c
Important:
Do not turn o the computer or the printer while updating.
Note:
If you cannot nd the application you want to update in the list, you cannot update using the EPSON Soware
Updater. Check for the latest versions of the applications from your local Epson website.
http://www.epson.com
Related Information
& “EPSON Soware Updater” on page 129
User's Guide
Applications and Network Service Information
135
