Code Problem Solution
411 A DNS error has occurred.
❏ Select Setup > System Administration > Wi-Fi/
Network Settings > Advanced Setup > DNS
Server, and then check the DNS settings.
❏ Check the DNS settings for the server, the
computer, or the access point.
412 An authentication error has occurred.
Select Setup > System Administration > Wi-Fi/
Network Settings > Advanced Setup > Email
Server > Server Settings, and then check the server
settings.
413 A communication error has occurred.
❏ Select Setup > System Administration > Wi-Fi/
Network Settings > Advanced Setup > Email
Server > Server Settings to check the email
server settings. You can check the cause of the
error by running connection check.
❏ The authentication method of the settings and
the email server may not match. When you select
O as the authentication method, make sure the
authentication method of the email server is set
to None.
❏ Check the network connection. See the Network
Guide for more details.
421 A DNS error has occurred.
❏ Select Setup > System Administration > Wi-Fi/
Network Settings > Advanced Setup > DNS
Server, and then check the DNS settings.
❏ Check the DNS settings for the server, the
computer, or the access point.
422 An authentication error has occurred.
Select Setup > System Administration > Fax
Settings > Output Settings > Fax Output > Other
Settings, and then check the settings of the folder
selected in Where to Forward.
423 A communication error has occurred. It is also
possible that a le with the same name is open or the
le is a read-only le.
❏ Check the network connection. See the Network
Guide for more details.
❏ Select Setup > System Administration > Fax
Settings > Output Settings > Fax Output >
Other Settings, and then check the settings of
the folder selected in Where to Forward.
❏ Close the
le
with the same name or disable the
read-only protection.
425 There is not enough storage space available in the
forwarding destination folder.
Increase the storage space in the forwarding
destination folder.
428 The destination was wrong or the destination does
not exist.
Select Setup > System Administration > Fax
Settings > Output Settings > Fax Output > Other
Settings, and then check the settings of the folder
selected in Where to Forward.
Related Information
& “Connecting to a Phone Line” on page 89
& “Scan Mode” on page 23
User's Guide
Solving Problems
141
