Menu Settings and Explanations
Layout Order
Select the copy layout for multiple pages when you have selected 2-up or 4-up as the Layout
setting.
Remove Shadow Removes shadows that appear in the center of copies when copying a booklet or that appear around
copies when copying thick paper.
Remove Punch
Holes
Removes the binding holes when copying.
Collate Copy Prints multiple copies of multiple originals collated in order and sorts them into sets.
Dry Time Select the drying time.
Advanced Settings Adjust image settings such as contrast and sharpness.
Scan Mode
Email
Menu Settings and Explanations
Contacts Select email addresses to send the scanned image from the contacts list.
Format
Select the format in which to save the scanned image. When you select TIFF (Single Page) or TIFF
(Multi Page), only monochrome scanning is available.
Menu Email Settings Subject: Enter a subject for the email.
Filename Prex: Enter a prex for the name of the le to be sent.
Basic Settings
See the list of menus in Settings.
Scan Report Prints a history that shows when and to which email address scanned les
have been sent.
Network Folder/FTP
Menu Settings and Explanations
Contacts Select a folder in which to save the scanned image from the contact list. You do not need to make
location settings when you have selected a folder from the contacts list.
Location Communication
Mode
Select the communication mode.
Location Enter a folder path in which to save the scanned image.
User Name Enter a user name for the specied folder.
Password Enter a password for the specied folder.
Connection Mode Select the connection mode.
Port Number Enter a port number.
Format
Select the format in which to save the scanned image. When you select TIFF (Single Page), only
monochrome scanning is available.
User's Guide
Printer Basics
23
