Solving Problems
Checking the Printer Status
You can check error messages and the approximate ink levels on the LCD screen or the computer.
Checking Messages on the LCD Screen
If an error message is displayed on the LCD screen, follow the on-screen instructions or the solutions below to
solve the problem.
Error Messages Solutions
Printer error. Turn the power o and on again.
For details, see your documentation.
Remove any paper or protective material in the printer and the paper
cassette. If the error message is still displayed after turning the power o
and on again, contact Epson support.
You need to replace the following ink cartridge. To ensure you receive premium print quality and to help protect your
print head, a variable ink safety reserve remains in the cartridge when
your printer indicates it is time to replace the cartridge. Replace the
cartridge when a message prompts you to do so.
Communication error. Please check the Wi-Fi/
network connection.
Connect the computer and the printer correctly. If you are connecting
over a network, see the Network Guide. If the error message is still
displayed, make sure that EPSON Scan and Document Capture Pro are
installed on the computer.
No dial tone detected.
This problem might be resolved by selecting Setup > System
Administration > Fax Settings > Basic Settings > Line Type, and then
selecting PBX. If your phone system requires an external access code to
get an outside line, set the access code after selecting PBX. Use # (hash)
instead of the actual access code when entering an outside fax number.
This makes connection more secure.
If the error message is still displayed, set the Dial Tone Detection
settings to disabled. However, disabling this feature may drop the
rst
digit of a fax number and send the fax to the wrong number.
Combination of the IP address and the subnet
mask is invalid. See your documentation.
See the Network Guide.
Recovery Mode The printer has started in recovery mode because the rmware update
failed. Follow the steps below to try to update the rmware again.
1. Connect the computer and the printer with a USB cable. (During
recovery mode, you cannot update the rmware over a network
connection.)
2. Visit your local Epson website for further instructions.
Related Information
& “Contacting Epson Support” on page 187
& “Installing Applications” on page 131
& “Updating Applications and Firmware” on page 135
User's Guide
Solving Problems
136
