Menu Settings and Explanations
Fax Report Fax Settings List Prints the current fax settings.
Fax Log Prints a transmission report automatically after you send a fax. You can set to
print this report automatically using the following menu.
Setup > System Administration > Fax Settings > Output Settings > Fax
Log Auto Print
Last Transmission Prints a report for the previous fax that was sent or received through polling.
Stored Fax
Documents
Prints a list of fax documents stored in the printer’s memory, such as
unnished
jobs.
Protocol Trace Prints a detailed report for the previous fax that was sent or received.
Related Information
& “Sending Many Pages of a Monochrome Document (Direct Send)” on page 98
& “Sending a Fax Preferentially (Priority Send)” on page 99
&
“Sending Dierent Size Documents Using ADF (Continuous Scan from ADF)” on page 99
&
“Sending Faxes at a Specied Time (Send Fax Later)” on page 97
&
“Receiving Faxes by Polling (Polling Receive)” on page 102
& “Sending Faxes on Demand (Polling Send)” on page 98
& “Storing a Fax Without Specifying a Recipient (Store Fax Data)” on page 97
Memory Device Mode
Note:
Memory device is a generic name for external USB devices such as USB ash drives.
File format
Menu Settings and Explanations
JPEG Select the le format of the le you want to print.
TIFF
PDF
Settings
Note:
Available menus vary depending on the selected le format.
Menu Settings and Explanations
Number of
printouts
Enter the number of printouts.
User's Guide
Printer Basics
26
