Menu Settings and Explanations
Wi-Fi/Network
Settings
Wi-Fi/Network
Status
Displays or prints the network settings and connection status.
Wi-Fi Setup Wi-Fi Setup Wizard See the Network Guide for more details.
Push Button Setup
(WPS)
PIN Code Setup
(WPS)
Wi-Fi Auto Connect
Disable Wi-Fi You may be able to resolve network problems by
disabling the Wi-Fi settings or making the Wi-Fi
settings again. See the Network Guide for more details.
Wi-Fi Direct Setup See the Network Guide for more details.
Connection Check Checks the status of the network connection and prints the network
connection check report. If there are any problems with the connection, see
the check report to solve the problem.
Advanced Setup See the Network Guide for more details.
Epson Connect
Services
You can suspend or resume the Epson Connect or Google Could Print service, or cancel using the
services (restore the default settings).
See the Epson Connect portal website for more details.
https://www.epsonconnect.com/
http://www.epsonconnect.eu (Europe only)
Google Cloud Print
Services
Copy Settings
The settings made in the User Default Settings are displayed as the default settings in each mode.
For details on the setting items, see the list of menus for each mode.
Scan Settings
Fax Settings
See the list of menus in Fax Settings.
Universal Print
Settings
These print settings are applied when printing from an external device without using the printer
driver, or when printing from a PostScript printer driver or PCL printer driver.
Top Oset Adjust the top or left margin of the paper.
Left Oset
Top Oset in Back Adjust the top margin or left margin for the back of the page when
performing 2-sided printing.
Left Oset in Back
Check Paper Width Checks the paper width before the printer starts printing. This prevents
printing beyond the edges of the paper when the paper size setting is not
correct, but the printing time may be little longer.
Dry Time Select the drying time when performing 2-sided printing.
Skip Blank Page Skips blank pages in the print data automatically.
PDL Print
Conguration
See the list of menus in PDL Print Conguration.
User's Guide
Printer Basics
30
