Menu Settings and Explanations
Basic Settings Fax Speed Select the fax transmission speed.
We recommend selecting Slow(9,600bps) when a communication error occurs
frequently, when sending/receiving a fax to/from abroad, or when you are using
an IP (VoIP) phone service.
ECM Automatically corrects errors in the fax transmission (Error Correction Mode),
mostly caused by telephone line noise. If this is disabled, you cannot send
documents in color.
Dial Tone
Detection
Detects a dial tone before starting to dial.
If the printer is connected to a PBX (Private Branch Exchange) or digital phone
line, the printer may fail to start dialing. In this situation, change the Line Type
setting to PBX. If this does not work, disable this feature. However, disabling this
feature may drop the rst digit of a fax number and send the fax to the wrong
number.
Dial Mode Select the type of phone system to which you have connected the printer. When
set to Pulse, you can temporarily switch the dialing mode from pulse to tone by
pressing
("T" is entered) while entering numbers on the fax top screen.
Depending on the region, this setting may not be displayed.
Line Type Select the line type to which you have connected the printer. For more details, see
the page that describes the settings for PBX.
Header Enter your sender name and fax number. These appear as a header on outgoing
faxes.
You can enter up to 40 characters for your name, and up to 20 digits for your fax
number.
Security Settings Direct Dialing
Restrictions
Enable this to prevent fax numbers from being entered manually allowing the
operator to select recipients only from the contacts list or sent history. Select
Enter Twice to require the operator to enter the fax number again when a
number is entered manually.
Conrm Address
List
Displays a recipient conrmation screen before starting the transmission.
Inbox Password
Settings
Select to password protect the inbox to restrict users from viewing received faxes.
Select Change to change the password, and select Reset to cancel password
protection. When changing or resetting the password, you need the current
password.
Backup Data
Auto Clear
Fax documents deleted by using the control panel disappear from the LCD screen,
but their backups are temporarily stored in the memory. The following features
delete backups.
Backup Data Auto Clear: Automatically deletes backups each time a sent or
received document is deleted.
Clear Backup Data: Deletes all backups. Run this before you give the printer to
someone else or dispose of it.
Clear Backup
Data
Check Fax
Connection
Checks if the printer is connected to the phone line and ready for fax transmission, and prints the check
result on A4 size plain paper.
Fax Setting
Wizard
Select to make basic fax settings by following the on-screen instructions.
For more details, see the page that describes basic fax settings.
User's Guide
Printer Basics
34
