Dimensions
Dimensions Storage
❏ Width: 461 mm (18.1 in.)
❏ Depth: 422 mm (16.6 in.)
❏ Height: 342 mm (13.5 in.)
Printing
❏ Width: 461 mm (18.1 in.)
❏ Depth: 655 mm (25.8 in.)
❏ Height: 383 mm (15.1 in.)
Weight
*
Approx. 14.1 kg (31.1 lb)
* Without the ink cartridges and the power cord.
Electrical
Specications
Model 100 to 240 V Model 220 to 240 V Model
Rated Frequency Range 50 to 60 Hz 50 to 60 Hz
Rated Current 0.8 to 0.4 A 0.4 A
Power Consumption (with USB Con-
nection)
Standalone copying: Approx. 22 W
(ISO/IEC24712)
Ready mode: Approx. 8.9 W
Sleep mode: Approx. 2.6 W
Power o: Approx. 0.4 W
Standalone copying: Approx. 22 W
(ISO/IEC24712)
Ready mode: Approx. 9.6 W
Sleep mode: Approx. 3.0 W
Power o: Approx. 0.4 W
Note:
❏ Check the label on the printer for its voltage.
❏ For European users, see the following Website for details on power consumption.
http://www.epson.eu/energy-consumption
❏ For users in Belgium, power consumption when copying may vary.
Check http://www.epson.be for the latest specications.
