Menu Settings and Explanations
Security Settings Access Control Requires the administrator password to operate the printer.
Select whether or not to allow jobs that do not have the necessary
authentication information.
Delete All
Condential Jobs
Deletes all saved condential jobs.
Eco Mode The following Eco mode settings are available. When these settings are disabled, the settings made in
Common Settings are applied.
Congure Sleep Timer Select the time period before the printer enters sleep
mode (energy saving mode) when no operations are
performed.
The LCD screen turns black when the set time passes.
LCD Brightness Adjust the brightness of the LCD screen.
2-Sided (Copy) Sets 2-sided copying as the default setting.
2-Sided (Memory
Device)
Sets 2-sided printing as the default setting.
Clear Internal
Memory Data
Deletes the print settings for a PostScript printer driver and a PCL printer driver.
Select Clear All to delete all of the data for a PostScript printer driver and a PCL printer driver that is
saved in the printer's memory.
Restore Default
Settings
Resets the selected settings to their defaults.
Related Information
& “Copy Mode” on page 22
& “Scan Mode” on page 23
& “Fax Settings” on page 32
&
“PDL Print Conguration” on page 35
Printer Settings
Select Setup > System Administration > Printer Settings from the home screen.
Menu Settings and Explanations
Paper Source Settings Rear Paper Feed Priority Feeds paper from the rear paper feed on a priority basis.
A4/Letter Auto Switching Feeds paper from the paper source set as A4 size when there is no
paper source set as Letter, or feeds from the paper source set as
Letter size when there is no paper source set as A4.
Auto Select Settings Specify which paper source to feed from when using features such
as copying and faxing. When there are multiple paper sources
available, paper is fed from the paper source with paper settings
that match the copy or print job.
Error Notice Displays an error message when the paper size or type settings in
Paper Setup and the print settings do not match.
User's Guide
Printer Basics
31
