Menu Settings and Explanations
Maintenance Print Head Nozzle
Check
Prints a pattern to check if the print head nozzles are clogged.
Print Head
Cleaning
Cleans clogged nozzles in the print head.
Print Head
Alignment
Adjusts the print head to improve print quality.
Run Vertical Alignment if your printouts look blurry.
Run Horizontal Alignment if your printouts contain horizontal banding at
regular intervals.
Run Ruled Line Alignment if text and lines are misaligned.
Thick Paper Reduces ink smearing when printing. Enable this feature only when you see
ink smearing on your printouts because it may lower the printing speed.
Paper Guide
Cleaning
Use this feature to feed paper for cleaning when there are ink stains on the
internal rollers.
Paper Setup Select the paper size and paper type you loaded in each paper source.
Print Status Sheet Conguration
Status Sheet
Prints an information sheet showing the current printer status and settings.
Supply Status
Sheet
Prints an information sheet showing the status of consumables.
Usage History
Sheet
Prints an information sheet showing the usage history of the printer.
PS3 Font List Prints a list of fonts that are available for a PostScript printer.
PCL Font List Prints a list of fonts that are available for a PCL printer.
Network Status Wi-Fi/Network
Status
Displays or prints the current network settings.
Wi-Fi Direct Status
Email Server Status Displays the current email server settings.
Epson Connect
Status
Displays whether or not the printer is registered and connected to Epson
Connect or Google Cloud Print service.
See the Epson Connect portal website for more details.
https://www.epsonconnect.com/
http://www.epsonconnect.eu (Europe only)
Google Cloud Print
Status
Admin Settings These menus allow an administrator to register an administrator password to protect the printer
settings from being changed by other users.
Admin Password Set, change, or reset the administrator password.
If you forget the password, contact your dealer.
Lock Setting
You need to enter an administrator password when you enter the System
Administration settings and when you change the settings of Eco Mode,
Presets, and the contacts.
System
Administration
See the pages that describe these features for more details.
User's Guide
Printer Basics
28
