Epson WorkForce Pro WF-M5690DWF [181/187] Saving power
![Epson WorkForce Pro WF-M5690DWF [181/187] Saving power](/views2/1168438/page181/bgb5.png)
Responsible use of copyrighted materials:
Printers can be misused by improperly copying copyrighted materials. Unless acting on the advice of a
knowledgeable attorney, be responsible and respectful by obtaining the permission of the copyright holder before
copying published material.
Saving Power
e printer enters sleep mode or turns o automatically if no operations are performed for a set period. You can
adjust the time before power management is applied. Any increase will aect the printer's energy eciency. Please
consider the environment before making any change.
Saving Power - Control Panel
1. Enter Setup from the home screen, and then select System Administration.
2. Select Common Settings.
3. Select Power
O
Timer or Sleep Timer, and then make settings.
Transporting the Printer
When you need to transport the printer to move or for repairs, follow the steps below to pack the printer.
c
Important:
❏ When storing or transporting the printer, avoid tilting it, placing it vertically, or turning it upside down;
otherwise ink may leak.
❏ Leave the ink cartridge installed. Removing the cartridge can dry out the print head and may prevent the printer
from printing.
❏ Leave the maintenance box installed; otherwise ink may leak during transporting.
1. Turn o the printer by pressing the
P
button.
2. Make sure the power light turns o, and then unplug the power cord.
c
Important:
Unplug the power cord when the power light is
o.
Otherwise, the print head does not return to the home
position causing the ink to dry, and printing may become impossible.
3. Disconnect all cables such as the power cord and USB cable.
4. Remove all of the paper from the printer.
5. Make sure there are no originals on the printer.
6. Store the paper support and the output tray.
User's Guide
Appendix
181
