Menu Settings and Explanations
Settings Paper Source Select the paper source that you want to use.
Quality Select the print quality.
If you select Best, the printing speed may be slower.
Date Select the format of the date on the printouts.
Fit Frame Crops the top and bottom edges of the image to t in the selected paper size.
Turning this o causes margins to appear on the left and right side of the
image.
Bidirectional Select which side to re ink when the print head moves. Turn this on under
normal usage.
Enabled: Prints when the print head moves in both directions.
Disabled: Prints only when the print head moves in one direction. Print
quality improves, but the printing speed is slow.
2-Sided Select 2-sided layout.
Print Order Last Page on Top: Prints from the rst page of a le.
First Page on Top: Prints from the last page of a le.
Image Adjustments Fix Photo Select the image correction method.
On: Enhances the image automatically by using Epson's unique image
analysis and image processing technology.
P.I.M.: Adjusts the image by using your camera's PRINT Image Matching or Exif
Print information.
Fix Red-Eye Fixes red-eye in photos.
Corrections are not applied to the original le, only to the printouts.
Depending on the type of photo, parts of the image other than the eyes may
be corrected.
Options Select Images
Select All Images selects all of the images on the memory device.
Select Group Select this menu to select another group.
Setup Mode
Menu Settings and Explanations
Ink Level Displays the approximate levels of the ink and the maintenance box.
When an ! icon is displayed, the ink is running low or the maintenance box is nearly full.
When a x icon is displayed, the ink is expended or the maintenance box is full.
User's Guide
Printer Basics
27
