Command Line Interface Reference Manual
102
(00)WORD X.121 address
Please Input the code of command to be excute(0-0): 0
Please input a string:1234 (input the x121 address)
Key Word:
Q(quit)
(00)<0-31> X29 pad profile number
(01)<cr>
Please Input the code of command to be excute(0-1): 0
Please input a string: 5 （input profile number）
Key Word:
Q(quit)
(00)r X29 pad profile read-only
(01)w X29 pad profile read-write
Please Input the code of command to be excute(0-1): 0
Key Word:
Q(quit)
(00<cr>
Please Input the code of command to be excute(0-0): 0
Will you excute it? (Y/N):y
4.4.6 Clear a Call
After you connect to a remote X.25 device, you can clear the connection by using the following commands :
Step Command
Purpose
1 ctrl-p
From the remote host, escape back to the local
router PAD mode.
2 Clr Clear the virtual call.
4.4.7 Customerize Local X.3 Parameter
To set an X.3 PAD parameter from a local terminal, use the following commands beginning in EXEC mode or User mode:
Step Command Purpose
1 pad address Enter X.28 mode.
3 Ctrl-p From X.28 mode escape back to PAD mode.
4 par Display the current X.3 PAD parameters.
5 set parameter-number: new-value Change the value of a parameter.
6 par Verify that the new PAD parameter was set
correctly.
[DEFAULT@Router /enable/]#pad
Key Word:
U(undo) D(default) Q(quit)
(00)svc pad to the remote x121 address
(01)pvc pad to the remote through pvc
Please Input the code of command to be excute(0-1): 1 （you could also input 0 to configure the pvc）
Key Word:
