Command Line Interface Reference Manual
462
l Example of voice gateway and gatekeeper configuration
Configure Voice over IP gateway
This section will specify how to configure VoIP gateway on an IP phone.
Configure gateway
To configure voice gateway, you should enter into voice gateway configure mode and use the following command in
global configure mode:
Command
Sub-command
and parameters
Function
gateway-cfg
Enter into voice gateway configure mode
to configure.
The basic step of voice gateway configure is as below:
Step
Command
Sub-command and
parameters
Function
1 ipaddr ipaddr
Configure the address used by gateway, thereinto
ipaddr must be an existing local address. (Support
virtual address)
2
gkid gkname ipaddr
ipaddr [port]
Configure the gatekeeper registered by gateway. If
port has not been
configured, it will use the default
port 1719. The default port is recommended (It must
be identical with port configure on GK.)
3 h323id string
Configure H.323 ID used by gateway. This ID will be
registered on gatekeeper. If it uses domain name form,
then the name suffix must be identical with domain
name configured on GK.
4
gateway
tech-prefix string
Configure the technique prefix registered on
gatekeeper. It can be multiple and is up to 8.
Note：Command gateway tech-prefix is invalide to the device registered to D-Link GK，because the command
gw-type-prefix D-Link currently supported is defined differently with Cisco. This command will be valid to device
registered to Cisco GK.
Examine tips
You can examine your voice gateway configuration through excuting the following tasks:
l Use command show gateway to show voice gateway configure state.
l Use command show running to show voice gateway configure content.
Troubleshooting tips
If you are having trouble connecting a call and you suspect the problem is associated with gateway configuration, you can
try to resolve the problem by performing the following tasks:
l Examine IP address and gatekeeper of the gateway.
l Use the command show getekway to confirm the voice gateway on the devices have been properly
configured.
l Use these debug commands: debug voip event asn、debug voip event ras、debug voip event gw.
Configure Voice over IP Gatekeeper
This section will show you how to configure VoIP gatekeeper.
Configure gatekeeper
