D-Link DI-3660 [251/506] Chongqing configuration
![D-Link DI-3660 [251/506] Chongqing configuration](/views2/1206859/page251/bgfb.png)
Command Line Interface Reference Manual
251
ｉｐ ａｄｄｒｅｓｓ １３０．１３０．０．１ ２５５．０．０．０
ｅｎｃａｐｓｕｌａｔｉｏｎ ｆｒａｍｅ－ｒｅｌａｙ
ｆｒａｍｅ－ｒｅｌａｙ ｍａｐ １３０．１３０．０．２ ｐｖｃ １０１ ｂｒｏａｄｃａｓｔ
ｆｒａｍｅ－ｒｅｌａｙ ｍａｐ １３０．１３０．０．４ ｐｖｃ １０２ ｂｒｏａｄｃａｓｔ
ｉｐ ｏｓｐｆ ｎｅｔｗｏｒｋ ｐｏｉｎｔ－ｔｏ－ｍｕｌｔｉｐｏｉｎｔ
！
ｒｏｕｔｅｒ ｏｓｐｆ １
ｎｅｔｗｏｒｋ １３０．１３０．０．０ ２５５．２５５．０．０ ａｒｅａ ０
GuangZhou Configuration:
ｈｏｓｔｎａｍｅ ｇｕａｎｇｚｈｏｕ
！
ｉｎｔｅｒｆａｃｅ ｓｅｒｉａｌ １／０
ｉｐ ａｄｄｒｅｓｓ １３０．１３０．０．４ ２５５．０．０．０
ｅｎｃａｐｓｕｌａｔｉｏｎ ｆｒａｍｅ－ｒｅｌａｙ
ｐｈｙｓｉｃａｌ ｓｐｅｅｄ １００００００
ｆｒａｍｅ－ｒｅｌａｙ ｍａｐ １３０．１３０．０．１ ｐｖｃ ４０１ ｂｒｏａｄｃａｓｔ
ｆｒａｍｅ－ｒｅｌａｙ ｍａｐ １３０．１３０．０．２ ｐｖｃ ４０２ ｂｒｏａｄｃａｓｔ
ｉｐ ｏｓｐｆ ｎｅｔｗｏｒｋ ｐｏｉｎｔ－ｔｏ－ｍｕｌｔｉｐｏｉｎｔ
！
ｒｏｕｔｅｒ ｏｓｐｆ １
ｎｅｔｗｏｒｋ １３０．１３０．０．０ ２５５．２５５．０．０ ａｒｅａ ０
ChongQing Configuration:
ｈｏｓｔｎａｍｅ ｃｈｏｎｇｑｉｎｇ
！
ｉｎｔｅｒｆａｃｅ ｓｅｒｉａｌ １／１
ｉｐ ａｄｄｒｅｓｓ １３０．１３０．０．３ ２５５．０．０．０
ｅｎｃａｐｓｕｌａｔｉｏｎ ｆｒａｍｅ－ｒｅｌａｙ
ｐｈｙｓｉｃａｌ ｓｐｅｅｄ ２００００００
ｆｒａｍｅ－ｒｅｌａｙ ｍａｐ １３０．１３０．０．２ ｐｖｃ ３０１ ｂｒｏａｄｃａｓｔ
ｉｐ ｏｓｐｆ ｎｅｔｗｏｒｋ ｐｏｉｎｔ－ｔｏ－ｍｕｌｔｉｐｏｉｎｔ
！
ｒｏｕｔｅｒ ｏｓｐｆ １
ｎｅｔｗｏｒｋ １３０．１３０．０．０ ２５５．２５５．０．０ ａｒｅａ ０
OSPF Point-to-Multipoint, Nonbroadcast Example
ｉｎｔｅｒｆａｃｅ Ｓｅｒｉａｌ１／０
ｉｐ ａｄｄｒｅｓｓ １０．０．１．１ ２５５．２５５．２５５．０
ｉｐ ｏｓｐｆ ｎｅｔｗｏｒｋ ｐｏｉｎｔ－ｔｏ－ｍｕｌｔｉｐｏｉｎｔ ｎｏｎ－ｂｒｏａｄｃａｓｔ
ｅｎｃａｐｓｕｌａｔｉｏｎ ｆｒａｍｅ－ｒｅｌａｙ
ｆｒａｍｅ－ｒｅｌａｙ ｌｏｃａｌ－ｄｌｃｉ ２００
ｆｒａｍｅ－ｒｅｌａｙ ｍａｐ １０．０．１．３ ｐｖｃ ２０２
ｆｒａｍｅ－ｒｅｌａｙ ｍａｐ １０．０．１．４ ｐｖｃ ２０３
ｆｒａｍｅ－ｒｅｌａｙ ｍａｐ １０．０．１．５ ｐｖｃ ２０４
ｎｏ ｓｈｕｔ
！
ｒｏｕｔｅｒ ｏｓｐｆ １
ｎｅｔｗｏｒｋ １０．０．１．０ ０．０．０．２５５ ａｒｅａ ０
ｎｅｉｇｈｂｏｒ １０．０．１．３ ｃｏｓｔ ５
ｎｅｉｇｈｂｏｒ １０．０．１．４ ｃｏｓｔ １０
