Command Line Interface Reference Manual
118
Repeat these steps for additional synchronous interfaces, if it’s needed.
Note: To configure set-dialer rotary-group interface, the PPP configuration will automatic synchronize with
corresponding dialer interface
To configure a dialer interface, use the following commands beginning in global configuration mode:
Step Command Purpose
1 interface dialer number Define a dialer rotary group
2 ip (undo) address Specifies no IP address for the interface.
3 dialer load-threshold load Specifies the dialer load threshold for
bringing up additional WAN links.
4 ppp multi-link Enable Multilink PPP.
For example:
[DEFAULT@Router /config/]#interface
Key Word:
U(undo) D(default) Q(quit)
……
(08)Dialer Dialer interface
(09)Multilink Multilink-group interface
……
Please Input the code of command to be excute(0-11): 8
Please input a interface name:d1 （input dialer interface）
Will you excute it? (Y/N):y
Key Word:
Q(quit)
……
(15)ip IP configuration commands
(16)mtu Set the interface MTU
……
Please Input the code of command to be excute(0-28): 15
Key Word:
U(undo) D(default) Q(quit)
(00)access-group Specify access control for packets
(01)address IP address
……
Please Input the code of command to be excute(0-18): u
Key Word:
U(undo) D(default) Q(quit)
(00)access-group Specify access control for packets
(01)address IP address
……
Please Input the code of command to be excute(0-18): 1
Key Word:
Q(quit)
(00)A.B.C.D IP address
(01)negotiated IP address negotiated over PPP or via DHCP
(02)<cr>
Please Input the code of command to be excute(0-2): 2
Will you excute it? (Y/N):y
Key Word:
