Command Line Interface Reference Manual
504
11.20 display L2TP packet information
display the IP packet information during establishing L2TP tunnel and session. Relative command as below:
command function
Ｄｅｂｕｇ ｌ２ｔｐ ｐａｃｋｅｔ Display L2TP packet information
［ＤＥＦＡＵＬＴ＠Ｒｏｕｔｅｒ ／ｅｎａｂｌｅ／］＃ｄｅｂｕｇ
Ｋｅｙ Ｗｏｒｄ：
Ｕ（ｕｎｄｏ） Ｄ（ｄｅｆａｕｌｔ） Ｑ（ｑｕｉｔ）
（００）ａａａ Ｄｅｂｕｇ ＡＡＡ ｐｒｏｃｅｓｓ ｉｎｆｏｒｍａｔｉｏｎ
．．．．．．
（１２）ｉｐ ＩＰ ｉｎｆｏｒｍａｔｉｏｎ
（１３）ｊｏｂ Ｄｅｂｕｇ ｊｏｂ ｉｎｆｏｒｍａｔｉｏｎ
（１４）ｌ２ｔｐ Ｌ２ＴＰ ｉｎｆｏｒｍａｔｉｏｎ
（１５）ｌａｐｂ ＬＡＰＢ ｉｎｆｏｒｍａｔｉｏｎ
（１６）ｌｉｎｅ ｒｅｃｖ ａｎｄ ｓｅｎｄ ｄａｔａ ｏｎ ｌｉｎｅ
－－Ｍｏｒｅ－－
１４
ｉｎｐｕｔ １４，ｓｅｌｅｃｔ １２ｔｐ
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）ｅｒｒｏｒ Ｌ２ＴＰ ｅｒｒｏｒ
（０１）ｅｖｅｎｔ Ｌ２ＴＰ ｅｖｅｎｔ
（０２）ｐａｃｋｅｔｓ Ｌ２ＴＰ ｐａｃｋｅｔｓ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－２）： ２
Ｉｎｐｕｔ ２，ｓｅｌｅｃｔ ｐａｃｋｅｔｓ
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）ｃｏｎｔｒｏｌ－ｐａｃｋｅｔｓ Ｌ２ＴＰ ｃｏｎｔｒｏｌ ｐａｃｋｅｔｓ
（０１）ｄａｔａ－ｐａｃｋｅｔｓ Ｌ２ＴＰ ｄａｔａ ｐａｃｋｅｔｓ
（０２）ｄｅｔａｉｌ Ｌ２ＴＰ ｐａｃｋｅｔｓ ｄｅｔａｉｌ
（０３）＜ｃｒ＞
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－３）： ２
ｎｏｔｅ： Ｃｈｏｏｓｅ ａｓ ｙｏｕｒ ｒｅｑｕｅｓｔ ｈｅｒｅ， ｆｏｒ ｅｘａｍｐｌｅ ２．
Ｗｉｌｌ ｙｏｕ ｅｘｃｕｔｅ ｉｔ？ （Ｙ／Ｎ）：ｙ
11.21 display the mistake during L2TP transferring
display the mistake during establishing L2TP tunnel and session, relative command as below:
command function
Ｄｅｂｕｇ ｌ２ｔｐ ｅｒｒｏｒ display the mistake during L2TP transferring
［ＤＥＦＡＵＬＴ＠Ｒｏｕｔｅｒ ／ｅｎａｂｌｅ／］＃ｄｅｂｕｇ
Ｋｅｙ Ｗｏｒｄ：
Ｕ（ｕｎｄｏ） Ｄ（ｄｅｆａｕｌｔ） Ｑ（ｑｕｉｔ）
（００）ａａａ Ｄｅｂｕｇ ＡＡＡ ｐｒｏｃｅｓｓ ｉｎｆｏｒｍａｔｉｏｎ
．．．．．．
（１２）ｉｐ ＩＰ ｉｎｆｏｒｍａｔｉｏｎ
（１３）ｊｏｂ Ｄｅｂｕｇ ｊｏｂ ｉｎｆｏｒｍａｔｉｏｎ
（１４）ｌ２ｔｐ Ｌ２ＴＰ ｉｎｆｏｒｍａｔｉｏｎ
（１５）ｌａｐｂ ＬＡＰＢ ｉｎｆｏｒｍａｔｉｏｎ
（１６）ｌｉｎｅ ｒｅｃｖ ａｎｄ ｓｅｎｄ ｄａｔａ ｏｎ ｌｉｎｅ
－－Ｍｏｒｅ－－
