Command Line Interface Reference Manual
23
for serial interface 1/0.
interface serial 1/0
encapsulation ppp
Example of interface description
Following example explain that how to add the description of interface. The description will be presented with displaying
of configuring file and interface command.
interface ethernet 1/1
description First Ethernet in network 1
ip address 192.168.1.23 255.255.255.0
Example of stop interface
Following example is of stop the Ethernet interface in port 1 of slot 1.
interface ethernet 1/1
shutdown
Following example is of restart interface
interface ethernet 1/1
shutdown(undo)
Following example is of stop an E1 channel
interface serial 1/3:23
shutdown
3.7 Configuring Interface
This chapter describes the processes for configuring interfaces. It contains these sections:
Please see the “Interface Configuration Example” later in this chapter to get the examples of configuring task. For
hardware technical descriptions and information about installing interfaces, refer to the hardware installation and
configuration manual for your product. For a complete description of the LAN interface commands used in this chapter,
refer to the "Interface configuration commands" chapter.
3.7.1 Configuring Ethernet Interface
In this section, we will describe the process of Ethernet interface configuring. D-Link Router supports the 10Mbps
Ethernet interface and 100Mbps Fast Ethernet interface. The concrete configurations consist of following steps. The first
step is prerequisite and others are optional.
♦ Assign the interface of Ethernet or FastEthernet
Input the commands below in global configuring mode to enter the status of Ethernet interface configuring
Command Function
interface ethernet slot/port Enter the mode of Ethernet interface configuring
interface fastethernet slot/port Enter the mode of FastEthernet interface configuring
Input the command “interface”, it will list all the parameters:
(00)FastEthernet FastEthernet interface
(01)Ethernet Ethernet interface
(02)Serial Serial interface
......
Please Input the code of command to be excute(0-10): 1
Input 1，choose the item “Ethernet”，it will prompt：
Please input a interface name:
Input the Ethernet, slot and port name:
Input 0 ，choose the item “Fast Ethernet”，it will display：
Please input a interface name:
