Command Line Interface Reference Manual
426
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）＜１－２１４７４８３＞ Ｆａｓｔ ｉｄｌｅ ｔｉｍｅ ｉｎ ｓｅｃｏｎｄｓ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－０）： ０
Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｄｉｇｉｔａｌ ｎｕｍｂｅｒ：２
ｎｏｔｅ：ｉｎｐｕｔ ｔｈｅ ｉｄｌｅ ｔｉｍｅ ｏｆ ｂｕｓｙ ｉｎｔｅｒｆａｃｅ ｈｅｒｅ，ｆｏｒ ｅｘａｍｐｌｅ ２．
Ｗｉｌｌ ｙｏｕ ｅｘｃｕｔｅ ｉｔ？ （Ｙ／Ｎ）：ｙ
3. Set dialer timeout
To set the minimum length of time an interface stays down before it is available to dial again after a line is disconnected
or fails.
Set line-down time: dialer enable-timeout seconds
Ｋｅｙ Ｗｏｒｄ：
Ｕ（ｕｎｄｏ） Ｄ（ｄｅｆａｕｌｔ） Ｑ（ｑｕｉｔ）
（００）ｃａｌｌｅｄ Ｄｉａｌｅｒ ｃａｌｌｅｄ ｓｔｒｉｎｇ
（０１）ｃａｌｌｅｒ Ｄｉａｌｅｒ ｃａｌｌｅｒ ｓｔｒｉｎｇ
（０２）ｄｔｒ Ｓｅｔ ＤＴＲ ｄｉａｌｉｎｇ ｆｏｒ ｉｎｔｅｒｆａｃｅ
（０３）ｅｎａｂｌｅ－ｔｉｍｅｏｕｔ Ｓｅｔ ｔｉｍｅ ｉｎｔｅｒｖａｌ ｂｅｔｗｅｅｎ ｌｉｎｅ ｄｏｗｎ ａｎｄ ｄｉａｌｉｎｇ
（０４）ｆａｓｔ－ｉｄｌｅ Ｓｅｔ ｉｄｌｅ ｔｉｍｅ ｗｈｅｎ ｌｉｎｅ ｃｏｎｔｅｎｔｉｏｎ
（０５）ｈｏｌｄ－ｑｕｅｕｅ Ｓｅｔ ｏｕｔｐｕｔ ｈｏｌｄ ｑｕｅｕｅ ｌｅｎｇｔｈ
（０６）ｉｄｌｅ－ｔｉｍｅｏｕｔ Ｓｅｔ ｉｄｌｅ ｔｉｍｅ ｂｅｆｏｒｅ ｄｉｓｃｏｎｎｅｃｔｉｎｇ ｌｉｎｅ
（０７）ｍａｐ Ｄｅｆｉｎｅ ｍｕｌｔｉｐｌｅ ｄｉａｌ－ｏｎ－ｄｅｍａｎｄ ｎｕｍｂｅｒｓ
（０８）ｐｒｉｏｒｉｔｙ Ｓｅｔ ｉｎｔｅｒｆａｃｅ ｐｒｉｏｒｉｔｙ ｉｎ ｄｉａｌｅｒ ｒｏｔａｒｙ ｇｒｏｕｐ
（０９）ｒｏｔａｒｙ－ｇｒｏｕｐ Ａｄｄ ｔｈｉｓ ｉｎｔｅｒｆａｃｅ ｔｏ ａ ｄｉａｌｅｒ ｒｏｔａｒｙ ｇｒｏｕｐ
（１０）ｓｔｒｉｎｇ Ｓｅｔ ｄｅｆａｕｌｔ ｔｅｌｅｐｈｏｎｅ ｎｕｍｂｅｒ
（１１）ｗａｉｔ－ｆｏｒ－ｃａｒｒｉｅｒ－ｔｉｍｅ Ｓｅｔ ｔｈｅ ｒｏｕｔｅｒ ｗａｉｔ ｆｏｒ ｃａｒｒｉｅｒ ｔｉｍｅ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１１）： ３（ｓｅｌｅｃｔ ｅｎａｂｌｅ－ｔｉｍｅｏｕｔ）
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）＜１－２１４７４８３＞ ｅｎａｂｌｅ－ｔｉｍｅ ｉｎ ｓｅｃｏｎｄｓ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－０）： ０
Ｉｎｐｕｔ ０，ｓｅｌｅｃｔ ｏｐｔｉｏｎ ＜１－２１４７４８３＞
Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｄｉｇｉｔａｌ ｎｕｍｂｅｒ：２
Ｎｏｔｅ：ｉｎｐｕｔ ｄｉａｌｅｒ ｔｉｍｅｏｕｔ ｈｅｒｅ，ｆｏｒ ｅｘａｍｐｌｅ ２．
Ｗｉｌｌ ｙｏｕ ｅｘｃｕｔｅ ｉｔ？ （Ｙ／Ｎ）：ｙ
4. Set Wait Time of carrying interface data
Set Wait Time of carrying interface data: dialer wait-for-carrier-time seconds
Ｋｅｙ Ｗｏｒｄ：
Ｕ（ｕｎｄｏ） Ｄ（ｄｅｆａｕｌｔ） Ｑ（ｑｕｉｔ）
Ｋｅｙ Ｗｏｒｄ：
Ｕ（ｕｎｄｏ） Ｄ（ｄｅｆａｕｌｔ） Ｑ（ｑｕｉｔ）
．．．．．．
（０９）ｒｏｔａｒｙ－ｇｒｏｕｐ Ａｄｄ ｔｈｉｓ ｉｎｔｅｒｆａｃｅ ｔｏ ａ ｄｉａｌｅｒ ｒｏｔａｒｙ ｇｒｏｕｐ
（１０）ｓｔｒｉｎｇ Ｓｅｔ ｄｅｆａｕｌｔ ｔｅｌｅｐｈｏｎｅ ｎｕｍｂｅｒ
（１１）ｗａｉｔ－ｆｏｒ－ｃａｒｒｉｅｒ－ｔｉｍｅ Ｓｅｔ ｔｈｅ ｒｏｕｔｅｒ ｗａｉｔ ｆｏｒ ｃａｒｒｉｅｒ ｔｉｍｅ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１１）： １１（ｓｅｌｅｃｔ ｏｐｔｉｏｎ ｗａｉｔ－ｆｏｒ－ｃａｒｒｉｅｒ－ｔｉｍｅ）
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
