Command Line Interface Reference Manual
491
Please input a digital number:Please input a string:
Input address，display：
(00) <0-1500> Largest I-frame size
Please Input the code of command to be excute(0-0): 0
Select 0，and input size。
Monitor SDLC Stations
To monitor the configuration of SDLC stations to determine which SDLC parameters need adjustment, use the following
command in EXEC mode:
Ｃｏｍｍａｎｄ Ｐｕｒｐｏｓｅ
ｓｈｏｗ ｉｎｔｅｒｆａｃｅｓ
Display SDLC station configuration information.
Input show command , display;
（００）ａｌｉａｓ ａｌｉａｓ ｆｏｒ ｃｏｍｍａｎｄ
．．．．．．
（１９）ｉｎｔｅｒｆａｃｅ ｉｎｔｅｒｆａｃｅ ｓｔａｔｕｓ ａｎｄ ｃｏｎｆｉｇｕｒａｔｉｏｎ
．．．．．．
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－４７）： １９
Ｉｎｐｕｔ １９，ｓｅｌｅｃｔ ｉｎｔｅｒｆａｃｅ ｉｔｅｍ ，ｄｉｓｐｌａｙ：
(00)FastEthernet FastEthernet interface
(01)Ethernet Ethernet interface
(02)Serial Serial interface
(03)Async Asynchronous interface
(04)Null Null interface
Please Input the code of command to be excute(0-4): <cr>
Select the configuration interface of the SDLC station to be displayed
Configuration Examples
The following sections provide SDLC configuration examples:
SDLC Two-Way Simultaneous Mode Configuration Example
SDLC Configuration for DLSw+ Example
Half-Duplex Configuration Example
sdlc Configuration Example 1-1
sdlc Configuration Example 1-2
SDLC Two-Way Simultaneous Mode Configuration Example
The following configuration defines serial interface 0 as the primary SDLC station with two SDLC secondary stations, C1
and C2, attached to it through a modem-sharing device. Two-way simultaneous mode is enabled.
config-interface serial 0
config-encap sdlc-primary
config-sdlc address c1
config-sdlc address c2
sdlc simultaneous full-datamode
The network for this configuration is shown in Figure 126.
Figure 126 Two SDLC Secondary Stations Attached to a Single Serial Interface through a Modem-Sharing Device
