Command Line Interface Reference Manual
405
（１８）ｕｎｒｅａｃｈａｂｌｅｓ Ｅｎａｂｌｅ ｓｅｎｄｉｎｇ ＩＣＭＰ Ｕｎｒｅａｃｈａｂｌｅ ｍｅｓｓａｇｅｓ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１８）： １５
Ｉｎｐｕｔ １５，ｓｅｌｅｃｔ ｒｔｐ：
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）ｃｏｍｐｒｅｓｓｉｏｎ－ｃｏｎｎｅｃｔｉｏｎｓ Ｍａｘｉｍｕｍ ｎｕｍｂｅｒ ｏｆ ｃｏｍｐｒｅｓｓｅｄ ｃｏｎｎｅｃｔｉｏｎｓ
（０１）ｈｅａｄｅｒ－ｃｏｍｐｒｅｓｓｉｏｎ Ｅｎａｂｌｅ ＲＴＰ ｈｅａｄｅｒ ｃｏｍｐｒｅｓｓｉｏｎ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１）：０
Ｉｎｐｕｔ ０，ｓｅｌｅｃｔ ｃｏｍｐｒｅｓｓｉｏｎ－ｃｏｎｎｅｃｔｉｏｎｓ
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）＜３－２５６＞ Ｎｕｍｂｅｒ ｏｆ ｃｏｎｎｅｃｔｉｏｎｓ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－０）： ０
Ｉｎｐｕｔ ０， ｓｅｌｅｃｔ ＜３－２５６＞ｏｐｔｉｏｎ， ｉｔ ｗｉｌｌ ｐｒｏｍｐｔ ｔｏ ｉｎｐｕｔ ｔｈｅ ｍａｘ ｃｏｎｎｅｃｔｉｏｎ ｎｕｍｂｅｒ：
Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｄｉｇｉｔａｌ ｎｕｍｂｅｒ：Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｓｔｒｉｎｇ：４５
Ｎｏｔｅ：Ｉｎｐｕｔ ｔｈｅ ｍａｘ ｃｏｎｎｅｃｔｉｏｎ ｎｕｍｂｅｒ ｏｆ ＣＲＴＰ ｈｅｒｅ， ４５ ｉｓ ｏｎｌｙ ｆｏｒ ｅｘａｍｐｌｅ．
Ｗｉｌｌ ｙｏｕ ｅｘｃｕｔｅ ｉｔ？ （Ｙ／Ｎ）：ｙ
７．３．４ Ｄｉｓｐｌａｙ ＣＲＴＰ Ｃｏｍｐｒｅｓｓｉｏｎ Ｉｎｆｏｒｍａｔｉｏｎ
Command Description
show ip rtp header-compression [type number] [detail]
display CRTP compression imformation
Ｔｈｅ ａｂｏｖｅ ｃｏｍｍａｎｄｓ ｎｅｅｄ ｔｏ ｂｅ ｃｏｎｆｉｇｕｒｅｄ ｕｎｄｅｒ ｔｈｅ ｇｌｏｂａｌ ｃｏｎｆｉｇｕｒａｔｉｏｎ ｄｉｒｅｃｔｏｒｙ．
［ＤＥＦＡＵＬＴ＠Ｒｏｕｔｅｒ ／ｅｎａｂｌｅ／］＃ｓｈｏｗ
Ｋｅｙ Ｗｏｒｄ：
Ｕ（ｕｎｄｏ） Ｄ（ｄｅｆａｕｌｔ） Ｑ（ｑｕｉｔ）
（００）ａｌｉａｓ ａｌｉａｓ ｆｏｒ ｃｏｍｍａｎｄ
（０１）ａｒｐ ＡＲＰ ｔａｂｌｅ
（０２）ｂａｃｋｕｐ Ｂａｋｕｐ ｓｔａｔｕｓ
（０３）ｂｏａｒｄ－ｉｎｆｏ Ｂｏａｒｄ ｉｎｆｏｒｍａｔｉｏｎ
（０４）ｂｒｅａｋ ｒｏｕｔｅｒ ｂｒｅａｋｐｏｉｎｔ ｉｎｆｏｒｍａｔｉｏｎ
（０５）
（０６）ｃｌａｓｓ－ｍａｐ ｓｈｏｗ ｃｌａｓｓ－ｍａｐ ｃｏｎｆｉｇｕｒａｔｉｏｎ
（０７）ｃｏｎｆｉｇｕｒａｔｉｏｎ ｓｈｏｗ ｃｏｎｆｉｇｕｒａｔｉｏｎ ｉｎ ｆｌａｓｈ ｍｅｍｏｒｙ
（０８）ｃｏｎｔｒｏｌｌｅｒ Ｉｎｔｅｒｆａｃｅ ｃｏｎｔｒｏｌｌｅｒ ｓｔａｔｕｓ
（０９）ｃｐｕ ｃｐｕ ｕｓａｇｅ ｉｎｆｏｒｍａｔｉｏｎ
（１０）ｄｅｂｕｇ Ｓｔａｔｅ ｏｆ ｅａｃｈ ｄｅｂｕｇｇｉｎｇ ｏｐｔｉｏｎ
（１１）ｄｈｃｐ ＤＨＣＰ ｉｎｆｏｒｍａｔｉｏｎ
（１２）ｄｉａｌｅｒ Ｄｉａｌｅｒ ｐａｒａｍｅｔｅｒｓ ａｎｄ ｓｔａｔｉｓｔｉｃｓ
（１３）ｆｒａｍｅ－ｒｅｌａｙ Ｄｉｓｐｌａｙ Ｆｒａｍｅ Ｒｅｌａｙ ｓｔａｔｅ
（１４）ｆｒｓｗｉｔｃｈ Ｄｉｓｐｌａｙ Ｆｒａｍｅ Ｒｅｌａｙ ｓｗｉｔｃｈ ｓｔａｔｅ
（１５）ｈｄｌｃ ＨＤＬＣ ｐａｒａｍｅｔｅｒｓ ａｎｄ ｓｔａｔｉｓｔｉｃｓ
（１６）ｈｏｓｔｓ Ｈｏｓｔ ｔａｂｌｅ
（１７）ｉｎｔｅｒｆａｃｅ ｉｎｔｅｒｆａｃｅ ｓｔａｔｕｓ ａｎｄ ｃｏｎｆｉｇｕｒａｔｉｏｎ
（１８）ｉｐ ＩＰ ｉｎｆｏｒｍａｔｉｏｎ
（１９）ｊｏｂ Ｊｏｂ ｐａｒａｍｅｔｅｒｓ ａｎｄ ｓｔａｔｉｓｔｉｃｓ
（２０）ｌ２ｔｐ Ｌ２ＴＰ ｉｎｆｏｒｍａｔｉｏｎ
－－Ｍｏｒｅ－－
１８
Ｉｎｐｕｔ １８，ｓｅｌｅｃｔ ｉｐ ｏｐｔｉｏｎ：
