![D-Link DI-3660 [114/506] Command purpose](/views2/1206859/page114/bg72.png)
Command Line Interface Reference Manual
114
Q(quit)
……
(26)physical-layer Configure physical layer parameters
(27)ppp Point-to-point protocol
……
Please Input the code of command to be excute(0-35): 27
Key Word:
U(undo) D(default) Q(quit)
(00)default Specify default parameters
(01)neighbor-route Create neighbor route to peer if needed
Please Input the code of command to be excute(0-1): 0
(00)ip Specify default IP parameters
Please Input the code of command to be excute(0-0): 0
(00)address Specify default IP address
Please Input the code of command to be excute(0-0): 0
(00)A.B.C.D Default IP address for remote end of this
interface
(01)dhcp Use DHCP proxy client to allocate a peer IP
address
(02)pool Use IP pool mechanism to allocate a peer IP address
Please Input the code of command to be excute(0-2):2
(00)WORD Name of IP address local-pool
Please Input the code of command to be excute(0-0): 0
Please input a string:D-link （input the ip pool name，the string “D -link” here is just for example）
Will you excute it? (Y/N):y
To define an IP address for a specified interface, use the following commands:
Command Purpose
ip local pool poolname
{begin-ip-address [ip-address-number]}
Creates one or more local IP address
pools.
interface type number
Specifies the interface and enters
interface configuration mode.
peer default config-ip addrip-address Specifies the specified address.
Key Word:
U(undo) D(default) Q(quit)
……
(25)peer Peer parameters for point to point interfaces
(26)physical-layer Configure physical layer parameters
……
Please Input the code of command to be excute(0-35): 25
Key Word:
U(undo) D(default) Q(quit)
(00)default Specify default parameters
(01)neighbor-route Create neighbor route to peer if needed
Please Input the code of command to be excute(0-1): 0
Key Word:
Q(quit)
