Command Line Interface Reference Manual
436
（０１）ｎｅｖｅｒ Ｎｅｖｅｒ ａｃｔｉｖａｔｅ ｔｈｅ ｂａｃｋｕｐ ｌｉｎｅ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１）： ０
ｎｏｔｅ：Ｓｅｌｅｃｔ ｗｈｅｔｈｅｒ ｔｈｅ ａｃｔｉｖａｔｅ ｄｅｌａｙ ｉｓ ｎｅｅｄｅｄ ｏｒ ｎｏｔ ｈｅｒｅ，ｆｏｒ ｅｘａｍｐｌｅ ０．
＜！［ｅｎｄｉｆ］＞Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｄｉｇｉｔａｌ ｎｕｍｂｅｒ：Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｓｔｒｉｎｇ：３４
ｎｏｔｅ：Ｉｆ ｓｅｌｅｃｔｉｎｇ ａｖｔｉｖａｔｅ ｄｅｌａｙ，ｉｎｐｕｔ ｔｉｍｅ ｈｅｒｅ，ｆｏｒ ｅｘａｍｐｌｅ ３４．
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）＜０－４２９４９６７２９４＞ Ｄｅａｃｔｉｖｅ Ｓｅｃｏｎｄｓ
（０１）ｎｅｖｅｒ Ｎｅｖｅｒ ｄｅａｃｔｉｖｅ ｔｈｅ ｂａｃｋｕｐ ｌｉｎｅ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１）： ０
ｎｏｔｅ： Ｄｅｔｅｒｍｉｎｅ ｗｈｅｔｈｅｒ ｄｉｓａｃｔｉｖａｔｅ ｄｅｌａｙ ｉｓ ｎｅｅｄｅｄ ｏｒ ｎｏｔ ｈｅｒｅ，ｆｏｒ ｅｘａｍｐｌｅ ０．
Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｄｉｇｉｔａｌ ｎｕｍｂｅｒ：Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｓｔｒｉｎｇ：２３
ｎｏｔｅ：Ｉｆ ｃｈｏｏｓｉｎｇ ｄｉｓａｃｔｉｖａｔｅ ｄｅｌａｙ，ｉｎｐｕｔ ｔｉｍｅ ｈｅｒｅ，ｆｏｒ ｅｘａｍｐｌｅ ２３．
Ｗｉｌｌ ｙｏｕ ｅｘｃｕｔｅ ｉｔ？ （Ｙ／Ｎ）：ｙ
8.10 launch flow equilibrium backup
Ｗｈｅｎ ｔｈｅ ａｃｔｕａｌ ｆｌｏｗ ｏｆ ｐｒｉｍａｒｙ ｉｎｔｅｒｆａｃｅ ｅｘｃｅｅｄｓ ｔｈｅ ｐｅｒｃｅｎｔ ｔｈｒｅｓｈｏｌｄ，ｔｈｅ ｂａｃｋｕｐ
ｉｎｔｅｒｆａｃｅ ｗｉｌｌ ｂｅ ａｃｔｉｖａｔｅｄ ｅｎｔｅｒｉｎｇ ｗｏｒｋｉｎｇ ｓｔａｔｕｓ． Ｈｏｗｅｖｅｒ，ｗｈｅｎ ｔｈｅ ｒａｔｉｏ ｏｆ ｔｈｅ ｐｒｉｍａｒｙ
ａｎｄ ｂａｃｋｕｐ ｉｎｔｅｒｆａｃｅ ａｃｔｕａｌ ｆｌｏｗ ｗｉｔｈ ｐｒｉｍａｒｙ ｉｎｔｅｒｆａｃｅ ｂａｎｄｗｉｄｔｈ ｉｓ ｌｏｗｅｒ ｔｈａｎ ｓｅｔｔｉｎｇ
ｔｈｒｅｓｈｏｌｄ，ｔｈｅ ｂａｃｋｕｐ ｉｎｔｅｒｆａｃｅ ｗｉｌｌ ｂｅ ｄｉｓａｃｔｉｖａｔｅｄ ａｎｄ ｅｎｔｅｒ ｂａｃｋｕｐ ｓｔａｔｕｓ．
ｌａｕｎｃｈ ｆｌｏｗ ｅｑｕｉｌｉｂｒｉｕｍ ｂａｃｋｕｐ，ｔｈｅ ｆｏｌｌｏｗｉｎｇ ｔａｓｋｓ ａｒｅ ｎｅｅｄｅｄ：
Ｆｉｒｓｔ ｓｔｅｐ，ｓｅｌｅｃｔ ｂａｃｋｕｐ ｉｎｔｅｒｆａｃｅ．
Second step,launch flow equilibrium on this interface.
first step,select backup interface.execute commands under interface configuration.
command function
backup interface slot/port
ｓｅｌｅｃｔ ｔｈｅ ｂａｃｋｕｐ ｉｎｔｅｒｆａｃｅ
［ＤＥＦＡＵＬＴ＠Ｒｏｕｔｅｒ ／ｃｏｎｆｉｇ／］＃ ｉｎｔｅｒｆａｃｅ
Ｋｅｙ Ｗｏｒｄ：
Ｕ（ｕｎｄｏ） Ｄ（ｄｅｆａｕｌｔ） Ｑ（ｑｕｉｔ）
（００）ＦａｓｔＥｔｈｅｒｎｅｔ ＦａｓｔＥｔｈｅｒｎｅｔ ｉｎｔｅｒｆａｃｅ
（０１）Ｅｔｈｅｒｎｅｔ Ｅｔｈｅｒｎｅｔ ｉｎｔｅｒｆａｃｅ
（０２）Ｓｅｒｉａｌ Ｓｅｒｉａｌ ｉｎｔｅｒｆａｃｅ
（０３）Ａｓｙｎｃ Ａｓｙｎｃｈｒｏｎｏｕｓ ｉｎｔｅｒｆａｃｅ
（０４）Ｎｕｌｌ Ｎｕｌｌ ｉｎｔｅｒｆａｃｅ
（０５）Ｌｏｏｐｂａｃｋ Ｌｏｏｐｂａｃｋ ｉｎｔｅｒｆａｃｅ
（０６）Ｔｕｎｎｅｌ Ｔｕｎｎｅｌ ｉｎｔｅｒｆａｃｅ
（０７）Ｄｉａｌｅｒ Ｄｉａｌｅｒ ｉｎｔｅｒｆａｃｅ
（０８）Ｍｕｌｔｉｌｉｎｋ Ｍｕｌｔｉｌｉｎｋ－ｇｒｏｕｐ ｉｎｔｅｒｆａｃｅ
（０９）Ｖｉｒｔｕａｌ－ｔｅｍｐｌａｔｅ Ｖｉｒｔｕａｌ ｔｅｍｐｌａｔｅ ｉｎｔｅｒｆａｃｅ
（１０）Ｖｉｒｔｕａｌ－ｔｕｎｎｅｌ Ｖｉｒｔｕａｌ ｔｕｎｎｅｌ ｉｎｔｅｒｆａｃｅ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１０）： ０
ｎｏｔｅ：Ｉｎｐｕｔ ｔｈｅ ｉｎｔｅｒｆａｃｅ ｎｅｅｄｓ ｔｏ ｃｏｎｆｉｇｕｒｅ ｂａｃｋｕｐ ｈｅｒｅ，ｆｏｒ ｅｘａｍｐｌｅ ＦａｓｔＥｔｈｅｒｎｅｔ．
Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｉｎｔｅｒｆａｃｅ ｎａｍｅ：ｆ０／０
ｎｏｔｅ：Ｉｎｐｕｔ ｉｎｔｅｒｆａｃｅ ｎａｍｅ ｈｅｒｅ，ｆｏｒ ｅｘａｍｐｌｅ ｆ０／０．
Ｗｉｌｌ ｙｏｕ ｅｘｃｕｔｅ ｉｔ？ （Ｙ／Ｎ）：ｙ
