Command Line Interface Reference Manual
16
ｍｏｎｉｔｏｒ＃ｃｏｐｙ ｔｆｔｐ ｆｌａｓｈ：ｓｔａｒｔｕｐ－ｃｏｎｆｉｇ
B．By SLIP zmodem.
ｍｏｎｉｔｏｒ＃ｄｏｗｎｌｏａｄ ｃ０ ｆｌａｓｈ：ｓｔａｒｔｕｐ－ｃｏｎｆｉｇ
２．３ Ｃｏｎｆｉｇｕｒｅ Ｅｔｈｅｒｎｅｔ ＩＰ Ａｄｄｒｅｓｓ
ｍｏｎｉｔｏｒ＃ｉｐ ａｄｄｒｅｓｓ ＜ｉｐ＿ａｄｄｒ＞ ＜ｎｅｔ＿ｍａｓｋ＞
This command is to configure the Ethernet IP address. The system default is １９２．１６８．０．１， subnet mask ２５５．２５５．２５５．０．
Parameter Description
ip_addr Ethernet IP address
net_mask Ethernet network mask
Example
ｍｏｎｉｔｏｒ＃ｉｐ ａｄｄｒｅｓｓ １９２．１６８．１．１ ２５５．２５５．２５５．０
２．４ Ｃｏｎｆｉｇｕｒｅ Ｔｈｅ Ｄｅｆａｕｌｔ Ｒｏｕｔｅ
ｍｏｎｉｔｏｒ＃ｉｐ ｒｏｕｔｅ ｄｅｆａｕｌｔ ＜ｉｐ＿ａｄｄｒ＞
This command is to configure the default route, and can configure only one route.
Parameter Description
ｉｐ＿ａｄｄｒ ＩＰ Address of the Gateway
Example
ｍｏｎｉｔｏｒ＃ｉｐ ｒｏｕｔｅ ｄｅｆａｕｌｔ １９２．１６８．１．１
２．５ Ｔｅｓｔ Ｎｅｔｗｏｒｋ Ｃｏｎｎｅｃｔｉｏｎ Ｂｙ ＰＩＮＧ
ｍｏｎｉｔｏｒ＃ｐｉｎｇ ＜ｉｐ＿ａｄｄｒｅｓｓ＞
This command is used for testing the connecting status of the network.
Parameter Description
ip_address Destination IP address
Example
ｍｏｎｉｔｏｒ＃ｐｉｎｇ １９２．１６８．０．１００
Ｒｅｐｌｙ ｆｒｏｍ １９２．１６８．０．１００ ： ｄａｔａ＝４８， ｔｉｍｅ＝１０ｍｓ， ｔｔｌ＝１２８
Ｒｅｐｌｙ ｆｒｏｍ １９２．１６８．０．１００ ： ｄａｔａ＝４８， ｔｉｍｅ＝１０ｍｓ， ｔｔｌ＝１２８
Ｒｅｐｌｙ ｆｒｏｍ １９２．１６８．０．１００ ： ｄａｔａ＝４８， ｔｉｍｅ＝１０ｍｓ， ｔｔｌ＝１２８
Ｒｅｐｌｙ ｆｒｏｍ １９２．１６８．０．１００ ： ｄａｔａ＝４８， ｔｉｍｅ＝１０ｍｓ， ｔｔｌ＝１２８
４ ｐａｃｋｅｔｓ ｓｅｎｔ， ４ ｐａｃｋｅｔｓ ｒｅｃｅｉｖｅｄ
ｒｏｕｎｄ－ｔｒｉｐ ｍｉｎ／ａｖｇ／ｍａｘ ＝ ０／２／１０ ｍｓ
２．６ Ｍａｎｕａｌｌｙ Ｂｏｏｔ Ｆｒｏｍ Ａ Ｆｉｌｅ
ｍｏｎｉｔｏｒ＃ｂｏｏｔ ｆｌａｓｈ ＜ｌｏｃａｌ＿ｆｉｌｅｎａｍｅ＞
This command is for starting some router software in the flash memory. There may be several router softwares in a flash.
Parameter Desription
local_filename is the filename saved in the flash memory and must be input by user.
Example
ｍｏｎｉｔｏｒ＃ｂｏｏｔ ｆｌａｓｈ ｒｏｕｔｅｒ．ｂｉｎ
