D-Link DI-3660 [54/506] Rmon event index
![D-Link DI-3660 [54/506] Rmon event index](/views2/1206859/page54/bg36.png)
Command Line Interface Reference Manual
54
2 .
rmon event index
[description
string] [log]
[owner string]
[trap community]
Add a RMON event table
7. l index is the index of the items，its range is 1~65535
8. l description is the descriptive information of the event
9. l log means that a log message will be added
to the log table
whenever the event is induced.
10. l trap means that a trap is generated when the event is induced,
community is the group name.
11. l owner string can be used to describe some descriptive message
of the event.
3 .
cd.. Back to management mode
4 . write Save the configuration
[DEFAULT@Router /config/]#rmon
Key Word:
U(undo) D(default) Q(quit)
(00)alarm Configure an RMON alarm
(01)event Configure an RMON event
Please Input the code of command to be excute(0-1): 1
Key Word:
Q(quit)
(00)<1-65535> event number
Please Input the code of command to be excute(0-0): 0
Please input a digital number:10 (input event number)
Key Word:
Q(quit)
(00)description Specify a description of the event
(01)log Generate RMON log when the event fires
……
Please Input the code of command to be excute(0-4): 0
Key Word:
Q(quit)
(00)WORD Event description
Please Input the code of command to be excute(0-0): 0
Please input a string:fire （input Event description）
Key Word:
Q(quit)
(00)log Generate RMON log when the event fires
(01)trap Generate SNMP trap when the event fires
……
Please Input the code of command to be excute(0-3): 0
Key Word:
Q(quit)
(00)trap Generate SNMP trap when the event fires
(01)owner Specify an owner for the event
(02)<CR>
Please Input the code of command to be excute(0-2): 1
Key Word:
Q(quit)
