Command Line Interface Reference Manual
222
5.8.5 Adjusting the BEIGRP Calculating Coefficient of Metrics
Sometimes you need to adjust the BEIGRP calculating coefficient of ｍｅｔｒｉｃｓ to finally effect the route select ing policy.
Although BEIGRP default calculating coefficient have been carefully select ed to provide excellent operation in most
networks, you need to adjust the BEIGRP calculating coefficient. Adjusting BEIGRP calculating coefficient of metric can
dramatically affect network performance, so the operation should be handled by the experienced engineer.
Command Purpose
metric weights k1 k2 k3 k4 k5 Adjusts the BEIGRP calculating
coefficient of ｍｅｔｒｉｃｓ
Select ｍｅｔｒｉｃ
Ｋｅｙ Ｗｏｒｄ：
Ｕ（ｕｎｄｏ） Ｄ（ｄｅｆａｕｌｔ） Ｑ（ｑｕｉｔ）
（００）ｗｅｉｇｈｔ Ｍｏｄｉｆｙ ＢＥＩＧＲＰ ｍｅｔｒｉｃ ｃｏｅｆｆｉｃｉｅｎｔｓ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－０）： ０
ｉｎｐｕｔ ０，Ｓｅｌｅｃｔ ｗｅｉｇｈｔ ｏｐｔｉｏｎ
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）＜０－４２９４９６７２９５＞ Ｋ１
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－０）： ０
ｉｎｐｕｔ ０，Ｓｅｌｅｃｔ ＜０－４２９４９６７２９５＞ ｏｐｔｉｏｎ
Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｄｉｇｉｔａｌ ｎｕｍｂｅｒ：Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｓｔｒｉｎｇ：２０
Ｎｏｔｅ：ｈｅｒｅ ｉｎｐｕｔ ｃｏｅｆｆｉｃｉｅｎｔ Ｋ１，２０ ｉｓ ｏｎｌｙ ａｎ ｅｘａｍｐｌｅ．．
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）＜０－４２９４９６７２９５＞ Ｋ２
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－０）： ０
ｉｎｐｕｔ ０，Ｓｅｌｅｃｔ ＜０－４２９４９６７２９５＞ ｏｐｔｉｏｎ
Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｄｉｇｉｔａｌ ｎｕｍｂｅｒ：Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｓｔｒｉｎｇ：３０
Ｎｏｔｅ：ｈｅｒｅ ｉｎｐｕｔ ｃｏｅｆｆｉｃｉｅｎｔ Ｋ２，３０ ｉｓ ｏｎｌｙ ａｎ ｅｘａｍｐｌｅ．．
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）＜０－４２９４９６７２９５＞ Ｋ３
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－０）： ０
ｉｎｐｕｔ ０，Ｓｅｌｅｃｔ ＜０－４２９４９６７２９５＞ ｏｐｔｉｏｎ
