Command Line Interface Reference Manual
497
Ｗｉｌｌ ｙｏｕ ｅｘｃｕｔｅ ｉｔ？ （Ｙ／Ｎ）：ｙ
Ｋｅｙ Ｗｏｒｄ：
Ｕ（ｕｎｄｏ） Ｄ（ｄｅｆａｕｌｔ） Ｑ（ｑｕｉｔ）
（００）Ｉｐ Ａｄｄ ＩＰ ｈｏｓｔ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－０）： ０
Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｉｐ ａｄｄｒｅｓｓ：１９２．１６８．１８．９０
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
．．．．．．
（００）ｐｒｉｏｒｉｔｙ
（０１）ｃｒ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１）：０
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
＜００＞ ５－１００ ｐｒｉｏｒｉｔｙ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１）：０
Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｓｔｒｉｎｇ： ４（ｉｎｐｕｔ ｐｒｉｏｒｉｔｙ，ｆｏｒ ｅｘａｍｐｌｅ ４）
Ｗｉｌｌ ｙｏｕ ｅｘｃｕｔｅ ｉｔ？ （Ｙ／Ｎ）：ｙ
11.6 set VPDN group local tunnel name
when LAC sends SCCRQ, the local tunnel name will be sent together, thus LNS will find local VDPN group based on the
remote tunnel name, the local tunnel name can include 244 bytes character string at least, relative command as follows:
command function
Ｌｏｃａｌｎａｍｅ ｌｏｃａｌ ｎａｍｅ
ｓｅｔ ＶＰＤＮ ｇｒｏｕｐ ｌｏｃａｌ ｔｕｎｎｅｌ ｎａｍｅ
Ｋｅｙ Ｗｏｒｄ：
Ｕ（ｕｎｄｏ） Ｄ（ｄｅｆａｕｌｔ） Ｑ（ｑｕｉｔ）
．．．．．．
（１３）ｉｎｔｅｒｆａｃｅ ｉｎｔｅｒｆａｃｅ ｃｏｎｆｉｇｕｒａｔｉｏｎ
（１４）ｌ２ｔｐ Ｌ２ＴＰ ｓｐｅｃｉｆｉｃ ｃｏｍｍａｎｄｓ
（１５）ｌｃｐ－ｒｅｎｅｇｏｔｉａｔｉｏｎ ｆｏｒｃｅ ＬＣＰ ｎｅｇｏｔｉａｔｅ ｌｏｃａｌｌｙ
（１６）ｌｏｃａｌ－ｎａｍｅ Ｌｏｃａｌ ｎａｍｅ ｕｓｅｄ ｆｏｒ ｇｒｏｕｐ ａｕｔｈｅｎｔｉｃａｔｉｏｎ
．．．．．．
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－２９）： １６（ｓｅｌｅｃｔ ｌｏｃａｌ－ｎａｍｅ）
Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｓｔｒｉｎｇ： ｎａｍｅ（ｉｎｐｕｔ ｌｏｃａｌ ｔｕｎｎｅｌ ｎａｍｅ， ｆｏｒ ｅｘａｍｐｌｅ ｎａｍｅ）
Ｗｉｌｌ ｙｏｕ ｅｘｃｕｔｅ ｉｔ？ （Ｙ／Ｎ）：ｙ
11.7 set remote LAC tunnel name connected with LNS
After receiving SCCRQ information, LNS will find VPDN group matching remote tunnel name with LAC tunnel name, so
LNS VPDN group can configure remote tunnel name which connect with LNS for matching after receiving SCCRQ information.
If a VPDN group doesn’t configure remote tunnel name, this group will be regarded as default VPDN group, when there is no
other matching VPDN group, this information will be adopted.
command function
Ｔｅｒｍｉｎａｔｅ－ｆｒｏｍ ｒｅｍｏｔｅ＿ｌａｃ＿ｎａｍｅ set remote LAC tunnel name connected with
LNS
Ｋｅｙ Ｗｏｒｄ：
Ｕ（ｕｎｄｏ） Ｄ（ｄｅｆａｕｌｔ） Ｑ（ｑｕｉｔ）
