U(undo) D(default) Q(quit)
(00)address Set local X.121 address
(01)alias Set address alias for this port
……
Please Input the code of command to be excute(0-26): 0
Key Word:
Q(quit)
(00)WORD Local X.121 address
Please Input the code of command to be excute(0-0): 0
Please input a string:123456 （input the x121 address）
Will you excute it? (Y/N):y
For an example of configuring the X.25 interface address, see the section "Typical X.25 Configuration Example" later in
this chapter.
4.3.2 Set default flow control values
Setting correct default flow control parameters of window size and packet size is essential for correct operation of the
link because X.25 is a strongly flow controlled protocol. However, it is easy to overlook this task because many networks
use standard default values. Mismatched default flow control values will cause X.25 local procedure errors, evidenced by
Clear and Reset events.
To configure flow control parameters, complete the tasks in the following sections.
l set default window size
l set default packet size
To configure X.25 flow control values, perform the following commands in interface configuration mode:
command
function
range default
x25 psize size Set the packet size(Byte) 128,256,512,1024 128
x25 wsize packets Set the window size
2-（modulo-1）
2
Key Word:
U(undo) D(default) Q(quit)
……
(18)psize Set X.25 max packet size
……
(25)wsize Set X.25 level 3 window size
(26)pad-access Accept only PAD connections from statically mapped X25 hosts
Please Input the code of command to be excute(0-26): 18 （you can also choose 25 to set the wsize）
Key Word:
Q(quit)
(00)<128-1024> Maximum input packet size (power of 2)
Please Input the code of command to be excute(0-0): 0
Please input a digital number:Please input a string:512 （input packet size）
Will you excute it? (Y/N):y
Note Because the X.25 protocol requires the DTE and DCE to have identical default maximum packet sizes
and default window sizes, changes made to the window and packet sizes when the interface is up are held until the
X.25 protocol restarts the packet service.
Configure additional X.25 interface parameters
