Command Line Interface Reference Manual
103
Q(quit)
(00)WORD X.121 address
Please Input the code of command to be excute(0-0): 0
Please input a string:1234 (input the x121 address)
Key Word:
Q(quit)
(00)<0-31> X29 pad profile number
(01)<cr>
Please Input the code of command to be excute(0-1): 1
Will you excute it? (Y/N):y
4.4.8 Monitor X.25 PAD Connection
To display currently opened connecting information, use the following EXE mode command:
Command Purpose
Show x25 To display currently opened X.25 connecting information
[DEFAULT@Router /config/]#show
Key Word:
……
(47)x25 Display X.25 state
(48)x25switch Show X.25 switch route table
(49)x29 Show X.29d X3 pad parameters
Please Input the code of command to be excute(0-49): 47
Key Word:
Q(quit)
(00)tcp Show X25-TCP State
(01)vc Display X.25 state
(02)xot Show XOT State
Please Input the code of command to be excute(0-2): 1
Key Word:
Q(quit)
(00)<cr>
Please Input the code of command to be excute(0-0): 0
Will you excute it? (Y/N):y
This information includes current status of virtual circuit.
4.4.8 X.25 PAD access limitation
This configuration can limit the source X121 address accessing the router.
Command function
X25 map pad x121addr Configuring the source X121 address for the static useful pad to access
the router
X25 pad-access Enable the pad-access limitation, the configuration will be checked by
using the item configured by the upper command. If it has not been
configured, all the pad access will be forbidden.
Input the following commands in the interface configurative mode:
[DEFAULT@Router /s0/1/]#x25
……
(11)map Set map from IP address to X.121 address
