Configure IP multicast flow control
Use ip multicast rate-limit to restrict the flow of multicast messages receiving or sending on a port in a range
source/group. Use no ip multicast rate-limit to disable flow control.
Use the following command to configure input stream of a multicast flow to be n kbps:
Step Command Purpose
１
ｉｐ ｍｕｌｔｉｃａｓｔ ｒａｔｅ－ｌｉｍｉｔ ｉｎ
ｇｒｏｕｐ－ｌｉｓｔ ａｃｃｅｓｓ－ｌｉｓｔ１
ｓｏｕｒｃｅ－ｌｉｓｔ ａｃｃｅｓｓ－ｌｉｓｔ２ ｎｋｂｐｓ
Ｃｏｎｆｉｇｕｒｅ ｔｈｅ ｍａｘｉｍｕｍ ｍｕｌｔｉｃａｓｔ
ｉｎｂｏｕｎｄ ｆｌｏｗ ｌｉｍｉｔ ｉｎ ａ ｒａｎｇｅ ｏｎ ｔｈｅ
ｐｏｒｔ．
Ｉｎ ｔｈｅ ｐａｒａｍｅｔｅｒ ｐｒｏｍｐｔ ｓｅｌｅｃｔ １７ ｏｐｔｉｏｎ ，ｐｒｏｍｐｔ ｉｓ ａｓ ｂｅｌｏｗ：
（００）ａｃｃｅｓｓ－ｇｒｏｕｐ Ｓｐｅｃｉｆｙ ａｃｃｅｓｓ ｃｏｎｔｒｏｌ ｆｏｒ ｐａｃｋｅｔｓ
．．．．．．
（１１）ｍｕｌｔｉｃａｓｔ Ｃｏｎｆｉｇ ｉｐ ｍｕｌｔｉｃａｓｔ ｐａｒａｍｅｔｅｒ
．．．．．．
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－２２）： １１
ｉｎｐｕｔ １１，Ｓｅｌｅｃｔ ｍｕｌｔｉｃａｓｔ ｏｐｔｉｏｎ ，ｐｒｏｍｐｔ：
（００）ｂｏｕｎｄａｒｙ Ｃｏｎｆｉｇ ｉｐ ｍｕｌｔｉｃａｓｔ ｂｏｕｎｄａｒｙ
（０１）ｈｅｌｐｅｒ－ｍａｐ Ｃｏｎｆｉｇ ｉｐ ｍｕｌｔｉｃａｓｔ ｈｅｌｐｅｒ ｍａｐ
（０２）ｒａｔｅ－ｌｉｍｉｔ Ｃｏｎｆｉｇ ｉｐ ｍｕｌｔｉｃａｓｔ ｒａｔｅ－ｌｉｍｉｔ ｔｅｒｍ
（０３）ｔｔｌ－ｔｈｒｅｓｈｏｌｄ Ｃｏｎｆｉｇ ｉｎｔｅｒｆａｃｅ ｔｔｌ ｔｈｒｅｓｈｏｌｄ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－３）： ２
ｉｎｐｕｔ ２，Ｓｅｌｅｃｔ ｒａｔｅ－ｌｉｍｉｔ ｏｐｔｉｏｎ ，ｐｒｏｍｐｔ ｉｓ ａｓ ｂｅｌｏｗ：
（００）ｉｎ Ｂｒｏａｄｃａｓｔ Ａｄｄｒｅｓｓ
（０１）ｏｕｔ ＩＰ Ｍｕｌｔｉｃａｓｔ Ａｄｄｒｅｓｓ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１）： ０
ｉｎｐｕｔ ０，Ｓｅｌｅｃｔ ｉｎ ｏｐｔｉｏｎ ，ｐｒｏｍｐｔ ｉｓ ａｓ ｂｅｌｏｗ：
（００）＜０－４２９４９６７＞ Ｒａｔｅ ｉｎ ｋｉｌｏｂｉｔｓ ｐｅｒ ｓｅｃｏｎｄ
（０１）ｇｒｏｕｐ－ｌｉｓｔ ＩＰ Ｍｕｌｔｉｃａｓｔ Ａｄｄｒｅｓｓ
（０２）ｓｏｕｒｃｅ－ｌｉｓｔ Ｂｒｏａｄｃａｓｔ Ａｄｄｒｅｓｓ
（０３）＜ｃｒ＞
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－３）： １
ｉｎｐｕｔ １，Ｓｅｌｅｃｔ ｇｒｏｕｐ－ｌｉｓｔ ｏｐｔｉｏｎ ，ｐｒｏｍｐｔ ｉｓ ａｓ ｂｅｌｏｗ：
（００）ＷＯＲＤ ＩＰ Ｓｔａｎｄａｒｄ Ａｃｃｅｓｓ Ｌｉｓｔ Ｎａｍｅ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－０）： ０
Ｓｅｌｅｃｔ ０ ｏｐｔｉｏｎ ，ｔｈｅｎ ｉｎｐｕｔ ａｃｃｅｓｓ－ｌｉｓｔ１，ｐｒｏｍｐｔ ｉｓ ａｓ ｂｅｌｏｗ：
（００）＜０－４２９４９６７＞ Ｒａｔｅ ｉｎ ｋｉｌｏｂｉｔｓ ｐｅｒ ｓｅｃｏｎｄ
（０１）ｓｏｕｒｃｅ－ｌｉｓｔ Ｂｒｏａｄｃａｓｔ Ａｄｄｒｅｓｓ
（０２）＜ｃｒ＞
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－２）： １
ｉｎｐｕｔ １，Ｓｅｌｅｃｔ ｓｏｕｒｃｅ－ｌｉｓｔ ｏｐｔｉｏｎ ，ｐｒｏｍｐｔ ｉｓ ａｓ ｂｅｌｏｗ：
