Command Line Interface Reference Manual
361
（００）ｐｅｅｒ Ａｌｌｏｗｅｄ Ｅｎｃｒｙｐｔｉｏｎ／Ｄｅｃｒｙｐｔｉｏｎ ｐｅｅｒ．
（０１）ｓｅｃｕｒｉｔｙ－ａｓｓｏｃｉａｔｉｏｎ Ｓｅｃｕｒｉｔｙ ａｓｓｏｃｉａｔｉｏｎ ｐａｒａｍｅｔｅｒｓ
（０２）ｔｒａｎｓｆｏｒｍ－ｓｅｔ Ｓｐｅｃｉｆｙ ｌｉｓｔ ｏｆ ｔｒａｎｓｆｏｒｍ ｓｅｔｓ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－２）： １
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）ｉｎｂｏｕｎｄ Ｉｎｂｏｕｎｄ ｍａｎｕａｌ ｓｅｃｕｒｉｔｙ ａｓｓｏｃｉａｔｉｏｎ
（０１）ｏｕｔｂｏｕｎｄ Ｏｕｔｂｏｕｎｄ ｍａｎｕａｌ ｓｅｃｕｒｉｔｙ ａｓｓｏｃｉａｔｉｏｎ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１）： １
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）ａｈ ＡＨ ｋｅｙ
（０１）ｅｓｐ ＥＳＰ ｋｅｙ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１）： ０
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）＜２５６－４２９４９６７２９５＞ ＳＰＩ ｆｏｒ ｓｅｃｕｒｉｔｙ ａｓｓｏｃｉａｔｉｏｎ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－０）： ０
Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｄｉｇｉｔａｌ ｎｕｍｂｅｒ：２００００ （Ｉｎｐｕｔ ＳＰＩ Ｖａｌｕｅ）
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）ＷＯＲＤ ｓｅｃｕｒｉｔｙ ａｓｓｏｃｉａｔｉｏｎ ｋｅｙ ｖａｌｕｅ （ｈｅｘ ｗ／ｏ ｌｅａｄｉｎｇ ０ｘ）
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－０）： ０
Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｓｔｒｉｎｇ：６５４３２１ （ｉｎｐｕｔ ｓｅｃｕｒｉｔｙ ａｓｓｏｃｉａｔｉｏｎ ｋｅｙ ｖａｌｕｅ ）
Ｗｉｌｌ ｙｏｕ ｅｘｃｕｔｅ ｉｔ？ （Ｙ／Ｎ）：ｙ
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
……
（０５）ｅｎｇｌｉｓｈ ｈｅｌｐ ｍｅｓｓａｇｅ ｉｎ Ｅｎｇｌｉｓｈ
（０６）ｅｘｉｔ ｅｘｉｔ ／ ｑｕｉｔ
……
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１９）： ６
Ｗｉｌｌ ｙｏｕ ｅｘｃｕｔｅ ｉｔ？ （Ｙ／Ｎ）：ｙ
Repeat these steps to create additional crypto map entries as required.
Creat Crypto Map Entries that Used IKE
To create crypto map entries that will use IKE to establish the security associations, use the following commands starting
in global configuration mode:
Step
Command Purpose
1
crypto map map-name seq-num
ipsec-isakmp
Specifies the crypto map entry to create (or modify). Perform
this command into the crypto map configuration mode.
2
Match address access-list-name
Configure an IPSec access list. This access list determines
which traffic should be protected by IPSec a
nd which traffic
should not be protected by IPSec security in the context of
this crypto map entry.
3
set peer ip-address
Specifies the address of IPSec peer. This is the address to
which IPSec protected traffic should be forwarded.
4
set transform-set transform-set-name1
Configure transform sets. No more than six crypto map
