Command Line Interface Reference Manual
332
n ？ Login Authentication Using TACACS+
Use the aaa authentication login command with the tacacs+ method keyword to specify TACACS+ as the login
authentication method. For example, to specify TACACS+ as the method of user authentication at login when no other
method list has been defined, enter the following command:
aaa (default) authentication login tacacs+
Before you can use TACACS+ as the login authentication method, you need to configure TACACS+ service. For more
information, refer to the “Configuring TACACS+“ chapter.
６．１．２．３．２ Ｕｓｅ ＡＡＡ Ｔｏ Ｐｒｏｃｅｅｄ ＰＰＰ Ａｕｔｈｅｎｔｉｆｉｃａｔｉｏｎ
Many users access network access servers through dialup via async or ISDN. The AAA security services facilitate a
variety of authentication methods for use on serial interfaces running PPP. Use the config-aaa authentication ppp
command to start AAA authentication no matter which of the supported PPP authentication methods you decide to use. To
configure AAA authentication methods for serial lines using PPP, use the following commands in global configuration
directory:
Step
Command Purpose
1
aaa (default) authentication ppp {list-name}
method1 [method2...]
Create a local authentication list.
2 interface interface-type number
Enter interface
configuration mode for the
interface to which you want to apply the
authentication list.
3
ppp (default) authentication {chap | pap | chap pap
| pap chap} {list-name}
Apply the authentication list to a line or set of
lines.
Ｅｘａｍｐｌｅ：
１． Ｃｒｅａｔ ａ ｖｅｒｙ ｌｏｗ ａｕｔｈｅｎｔｉｃａｔｉｏｎ ｌｉｓｔ：
［ＤＥＦＡＵＬＴ＠Ｒｏｕｔｅｒ ／ｃｏｎｆｉｇ／］＃ａａａ
（００）ａｃｃｏｕｎｔｉｎｇ Ａｃｃｏｕｎｔｉｎｇ ｃｏｎｆｉｇｕｒａｔｉｏｎｓ ｐａｒａｍｅｔｅｒｓ
（０１）ａｕｔｈｅｎｔｉｃａｔｉｏｎ Ａｕｔｈｅｎｔｉｃａｔｉｏｎ ｃｏｎｆｉｇｕｒａｔｉｏｎｓ ｐａｒａｍｅｔｅｒｓ
……
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－５）： １
……
（０３）ｐｐｐ Ｓｅｔ ａｕｔｈｅｎｔｉｃａｔｉｏｎ ｌｉｓｔ ｆｏｒ ｐｐｐ
（０４）ｕｓｅｒｎａｍｅ－ｐｒｏｍｐｔ Ｔｅｘｔ ｔｏ ｕｓｅ ｗｈｅｎ ｐｒｏｍｐｔｉｎｇ ｆｏｒ ａ ｕｓｅｒｎａｍｅ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－４）： ３
（００）ＷＯＲＤ Ｎａｍｅｄ ａｕｔｈｅｎｔｉｃａｔｉｏｎ ｌｉｓｔ
（０１）ｄｅｆａｕｌｔ Ｔｈｅ ｄｅｆａｕｌｔ ａｕｔｈｅｎｔｉｃａｔｉｏｎ ｌｉｓｔ．
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１）： ０
Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｓｔｒｉｎｇ：ｂｄｃｏｍ （ｉｎｐｕｔ ａｕｔｈｅｎｔｉｃａｔｉｏｎ ｌｉｓｔ）
（００）ｇｒｏｕｐ Ｕｓｅ Ｓｅｒｖｅｒ－ｇｒｏｕｐ
（０１）ｇｒｏｕｐ－ｒｅｓｔｒｉｃｔ Ｉｆ ｕｓｅｒ ｈａｓ ｓｐｅｃｉｆｉｅｄ ａ ｓｅｒｖｅｒ，ｔｈｉｓ ｇｒｏｕｐ ｗｉｌｌ ｎｏｔ ｂｅ ｕｓｅｄ
（０２）ｌｏｃａｌ Ｕｓｅ ｌｏｃａｌ ｕｓｅｒｎａｍｅ ａｕｔｈｅｎｔｉｃａｔｉｏｎ
……
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－６）： ２
……
（０３）ｒａｄｉｕｓ Ｕｓｅ ａｌｌ ｒａｄｉｕｓ ｓｅｒｖｅｒ ｆｏｒ ａｕｔｈｅｎｔｉｃａｔｉｏｎ
