Command Line Interface Reference Manual
501
（０３）ｒｅｃｅｉｖｅ－ｗｉｎｄｏｗ Ｒｅｃｅｉｖｅ ｗｉｎｄｏｗ ｓｉｚｅ ｆｏｒ ｃｏｎｔｒｏｌ ｃｈａｎｎｅｌ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－３）： ２（ｓｅｌｅｃｔ ｐａｓｓｗｏｒｄ）
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
＜００＞ ＷＯＲＤ ｐａｓｓｗｏｒｄ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１）：０
Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｓｔｒｉｎｇ：ｗｏｒｄ（ｉｎｐｕｔ ｐａｓｓｗｏｒｄ， ｆｏｒ ｅｘａｍｐｌｅ ｗｏｒｄ）
Ｗｉｌｌ ｙｏｕ ｅｘｃｕｔｅ ｉｔ？ （Ｙ／Ｎ）：ｙ
11.15 set time interval of sending HELLO diagram
after session establishing successfully, LAC and LNS will send HELLO diagram to each other regularly for testing the line.
The time interval of sending HELLO diagram can be assigned from ０ｓ ｔｏ ４２９４９６７２９４ｓ．ｒｅｌａｔｉｖｅ ｃｏｍｍａｎｄ ａｓ ｂｅｌｏｗ：
command function
Ｌ２ｔｐ ｔｕｎｎｅｌ ｈｅｌｌｏ ｈｅｌｌｏｉｎｔｅｒｖａｌ set time interval of sending HELLO diagram
［ＤＥＦＡＵＬＴ＠Ｒｏｕｔｅｒ ／ｖｐｄｎ／］＃ｌ２ｔｐ
Ｋｅｙ Ｗｏｒｄ：
Ｕ（ｕｎｄｏ） Ｄ（ｄｅｆａｕｌｔ） Ｑ（ｑｕｉｔ）
（００）ｔｕｎｎｅｌ Ｌ２ＴＰ ｔｕｎｎｅｌ ｃｏｍｍａｎｄｓ
（０１）ｈｉｄｄｅｎ Ａｌｌｏｗ ＡＶＰｓ ｔｏ ｂｅ ｈｉｄｄｅｎ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１）： ０
ｉｎｐｕｔ ０，ｓｅｌｅｃｔ ｔｕｎｎｅｌ：
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）ａｕｔｈｅｎｔｉｃａｔｉｏｎ Ａｕｔｈｅｎｔｉｃａｔｅ ｔｕｎｎｅｌ
（０１）ｈｅｌｌｏ Ｈｅｌｌｏ ｐａｃｋｅｔ ｉｎｔｅｒｖａｌ
（０２）ｐａｓｓｗｏｒｄ Ｔｕｎｎｅｌ ｐａｓｓｗｏｒｄ ｆｏｒ ａｕｔｈｅｎｔｉｃａｔｉｏｎ ａｎｄ／ｏｒ ＡＶＰ ｈｉｄｉｎｇ
（０３）ｒｅｃｅｉｖｅ－ｗｉｎｄｏｗ Ｒｅｃｅｉｖｅ ｗｉｎｄｏｗ ｓｉｚｅ ｆｏｒ ｃｏｎｔｒｏｌ ｃｈａｎｎｅｌ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－３）： １（ｓｅｌｅｃｔ ｈｅｌｌｏ）
Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｓｔｒｉｎｇ：１０（ｉｎｐｕｔ ｔｉｍｅ ｉｎｔｅｒｖａｌ， ｆｏｒ ｅｘａｍｐｌｅ １０）
Ｗｉｌｌ ｙｏｕ ｅｘｃｕｔｅ ｉｔ？ （Ｙ／Ｎ）：ｙ
11.16 set tunnel accepting window size
this command is used to specify local accepting BUFFER size. At the same time, it will notify the opposite when the L2TP
tunnel negotiating. the opposite station specify the sliding window size of corresponding sent diagram. The size can change
from 1 to 100,
relative setting command as below：
command function
Ｌ２ｔｐ ｔｕｎｎｅｌ ｒｅｃｅｉｖｅ－ｗｉｎｄｏｗ
ｒｅｃｅｉｖｅ－ｗｉｎｄｏｗ－ｓｉｚｅ
set tunnel accepting window size
［ＤＥＦＡＵＬＴ＠Ｒｏｕｔｅｒ ／ｖｐｄｎ／］＃ｌ２ｔｐ
Ｋｅｙ Ｗｏｒｄ：
Ｕ（ｕｎｄｏ） Ｄ（ｄｅｆａｕｌｔ） Ｑ（ｑｕｉｔ）
（００）ｔｕｎｎｅｌ Ｌ２ＴＰ ｔｕｎｎｅｌ ｃｏｍｍａｎｄｓ
（０１）ｈｉｄｄｅｎ Ａｌｌｏｗ ＡＶＰｓ ｔｏ ｂｅ ｈｉｄｄｅｎ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１）： ０
ｉｎｐｕｔ ０，ｓｅｌｅｃｔ ｔｕｎｎｅｌ：
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）ａｕｔｈｅｎｔｉｃａｔｉｏｎ Ａｕｔｈｅｎｔｉｃａｔｅ ｔｕｎｎｅｌ
