Command Line Interface Reference Manual
416
dialer-group number
dialer rotary-group number
dialer string dialer-string
dialer load-threshold enable_threshold disable_threshold
dialer enable-timeout seconds
dialer idle-timeout seconds
dialer fast-idle seconds
dialer priority number
dialer dtr
８．５ Configuring an Interface to Send and Receive calling
1. Send call to an interface and accept call from the one
In command to send call to an interface and accept call from the one, you can perform the configuration tasks below with
PPP encapsulation.
l enter physical interface configuration mode ｉｎｔｅｒｆａｃｅ ｉｎｔｅｒｆａｃｅ－ｔｙｐｅ ｉｎｔｅｒｆａｃｅ－ｎｕｍｂｅｒ
［ＤＥＦＡＵＬＴ＠Ｒｏｕｔｅｒ ／ｃｏｎｆｉｇ／］＃ｉｎｔｅｒｆａｃｅ
Ｋｅｙ Ｗｏｒｄ：
Ｕ（ｕｎｄｏ） Ｄ（ｄｅｆａｕｌｔ） Ｑ（ｑｕｉｔ）
（００）ＦａｓｔＥｔｈｅｒｎｅｔ ＦａｓｔＥｔｈｅｒｎｅｔ ｉｎｔｅｒｆａｃｅ
（０１）Ｅｔｈｅｒｎｅｔ Ｅｔｈｅｒｎｅｔ ｉｎｔｅｒｆａｃｅ
（０２）Ｓｅｒｉａｌ Ｓｅｒｉａｌ ｉｎｔｅｒｆａｃｅ
（０３）Ａｓｙｎｃ Ａｓｙｎｃｈｒｏｎｏｕｓ ｉｎｔｅｒｆａｃｅ
（０４）Ｎｕｌｌ Ｎｕｌｌ ｉｎｔｅｒｆａｃｅ
（０５）Ｌｏｏｐｂａｃｋ Ｌｏｏｐｂａｃｋ ｉｎｔｅｒｆａｃｅ
（０６）Ｔｕｎｎｅｌ Ｔｕｎｎｅｌ ｉｎｔｅｒｆａｃｅ
（０７）Ｄｉａｌｅｒ Ｄｉａｌｅｒ ｉｎｔｅｒｆａｃｅ
（０８）Ｍｕｌｔｉｌｉｎｋ Ｍｕｌｔｉｌｉｎｋ－ｇｒｏｕｐ ｉｎｔｅｒｆａｃｅ
（０９）Ｖｉｒｔｕａｌ－ｔｅｍｐｌａｔｅ Ｖｉｒｔｕａｌ ｔｅｍｐｌａｔｅ ｉｎｔｅｒｆａｃｅ
（１０）Ｖｉｒｔｕａｌ－ｔｕｎｎｅｌ Ｖｉｒｔｕａｌ ｔｕｎｎｅｌ ｉｎｔｅｒｆａｃｅ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１０）： ２ （ｓｅｌｅｃｔ ｓｅｒｉａｌｉｎｔｅｒｆａｃｅ）
Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｉｎｔｅｒｆａｃｅ ｎａｍｅ：ｓ２／０
Ｗｉｌｌ ｙｏｕ ｅｘｃｕｔｅ ｉｔ？ （Ｙ／Ｎ）：ｙ
l configuring the dialer method: line dial
Ｋｅｙ Ｗｏｒｄ：
Ｑ（ｑｕｉｔ）
（００）ｂａｃｋｕｐ Ｍｏｄｉｆｙ ｂａｃｋｕｐ ｐａｒａｍｅｔｅｒｓ
（０１）ｂａｎｄｗｉｄｔｈ Ｓｅｔ ｔｈｅ ｉｎｔｅｒｆａｃｅ ｂａｎｄｗｉｄｔｈ
（０２）ｃｈｉｎｅｓｅ ｈｅｌｐ ｍｅｓｓａｇｅ ｉｎ Ｃｈｉｎｅｓｅ
（０３）ｃｈｍｅｍ Ｃｈａｎｇｅ ｍｅｍｏｒｙ ｏｆ ｓｙｓｔｅｍ
（０４）ｃｌｅａｒ＿ｄｒｖ ｃｌｅａｒ ｉｎｔｅｒｆａｃｅ ｓｔａｔｉｓｔｉｃ ｃｏｕｎｔｅｒ
（０５）ｃｒｙｐｔｏ Ｅｎｃｒｙｐｔｉｏｎ ｍｏｄｕｌｅ
（０６）ｃｕｓｔｏｍ－ｑｕｅｕｅ－ｌｉｓｔ Ａｓｓｉｇｎ ａ ｃｕｓｔｏｍ ｑｕｅｕｅ ｌｉｓｔ ｔｏ ｉｎｔｅｒｆａｃｅ
（０７）ｄｅｆａｕｌｔ ｒｅｓｔｏｒｅ ｄｅｆａｕｌｔ ｃｏｎｆｉｇｕｒａｔｉｏｎ
（０８）ｄｅｌａｙ Ｓｅｔ ｔｈｅ ｉｎｔｅｒｆａｃｅ ｄｅｌａｙ
（０９）ｄｅｓｃｒｉｐｔｉｏｎ Ｓｅｔ ｔｈｅ ｉｎｔｅｒｆａｃｅ ｄｅｓｃｒｉｐｔｉｏｎ
（１０）ｄｓｒ－ｉｇｎｏｒｅ ｉｇｎｏｒｅ ｄｓｒ ｓｉｇｎａｌ
（１１）ｅｎｃａｐｓｕｌａｔｉｏｎ Ｓｅｔ ｅｎｃａｐｓｕｌａｔｉｏｎ ｔｙｐｅ ｆｏｒ ａｎ ｉｎｔｅｒｆａｃｅ
（１２）ｅｎｇｌｉｓｈ ｈｅｌｐ ｍｅｓｓａｇｅ ｉｎ Ｅｎｇｌｉｓｈ
（１３）ｅｘｉｔ ｅｘｉｔ ／ ｑｕｉｔ
