Command Line Interface Reference Manual
153
be introduced in latter documents.
Configure Broadcasting Message Processing
A broadcast message destined for all hosts on a particular physical network. Network hosts recognize broadcasts by
special addresses. Broadcasts are heavily used by some protocols, including several important Internet protocols. Control
of broadcast messages is an essential part of the IP network administrator's job. The system supports directed broadcast,
i.e. broadcast destined for a special network. Broadcast to all the subnets of a network dose not supported by the system.
Several early IP implementations do not use the current broadcast address standard. Instead, they use the old standard,
which calls for all “0” instead of all “1” to indicate broadcast address. Our system can identify and accept messages in
both forms.
Allow Translation from Directed Broadcast to Physical Broadcast
Forward UDP Broadcast Packets and Protocols
Allow Translation From Directed Broadcast To Physical Broadcast
By default, IP directed broadcast packet will be discarded but not transmitting. The discarded IP directed broadcast packet
avoid most of attacking for Router, such as “service denied”.
You can enable forwarding of IP broadcasts on an interface where the directed broadcast becomes a physical broadcast.
Once the function is enabled, all directed broadcast packets reaching the network the interface residing in will be
forwarded to this interface, and then be transmitted as physical broadcast packets.
Perform the following command tasks in interface configuration mode to enable the directed broadcast forwarding:
Command Task
ip directed-broadcast [access-list-name] Enable translation from directed broadcast to physical
broadcast on an interface.
Ｓｅｌｅｃｔ ｉｐ ｏｐｔｉｏｎ ｉｎ ｔｈｅ ｐｒｏｍｐｔ， ｉｔ ｗｉｌｌ ｌｉｓｔ ａｌｌ ａｒｇｕｍｅｎｔｓ：
（００）ａｃｃｅｓｓ－ｇｒｏｕｐ Ｓｐｅｃｉｆｙ ａｃｃｅｓｓ ｃｏｎｔｒｏｌ ｆｏｒ ｐａｃｋｅｔｓ
（０１）ａｄｄｒｅｓｓ ＩＰ ａｄｄｒｅｓｓ
（０２）ｂｅｉｇｒｐ Ｅｎｈａｎｃｅｄ Ｉｎｔｅｒｉｏｒ Ｇａｔｅｗａｙ Ｒｏｕｔｉｎｇ Ｐｒｏｔｏｃｏｌ
（０３）ｄｉｒｅｃｔｅｄ－ｂｒｏａｄｃａｓｔ Ｅｎａｂｌｅ ｆｏｒｗａｒｄｉｎｇ ｏｆ ｄｉｒｅｃｔｅｄ ｂｒｏａｄｃａｓｔｓ
．．．．．．
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１９）： ３
Ｉｎｐｕｔ ３，ｓｅｌｅｃｔ ｄｉｒｅｃｔｅｄ－ｂｒｏａｄｃａｓｔ ｏｐｔｉｏｎ，ｐｒｏｍｐｔ ｉｓ ａｓ ｂｅｌｏｗ：
（００）ＷＯＲＤ － Ａｃｃｅｓｓ－ｌｉｓｔ ｎａｍｅ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－０）： ０
Ｉｎｐｕｔ ０，ｓｅｌｅｃｔ ＷＯＲＤ ｏｐｔｉｏｎ，ｐｒｏｍｐｔ ｉｓ ａｓ ｂｅｌｏｗ：
Ｐｌｅａｓｅ ｉｎｐｕｔ Ａｃｃｅｓｓ－ｌｉｓｔ Ｎａｍｅ：
Ｉｎｐｕｔ ａｃｃｅｓｓ－ｌｉｓｔ－ｎａｍｅ．
Forward UDP Broadcast Packets
Network hosts occasionally use UDP broadcasts to determine address, configuration, and name information. If such a host
is on a network segment that does not include a server, UDP broadcasts are normally not forwarded. You can remedy this
situation by configuring the interface of your router to forward certain classes of broadcasts to a helper address. You can
have more than one helper address per interface.
