![D-Link DI-3660 [18/506] I nt roduct i on of i nt erf ace conf i gurat i on](/img/pdf.png)
D-Link DI-3660 [18/506] I nt roduct i on of i nt erf ace conf i gurat i on
![D-Link DI-3660 [18/506] I nt roduct i on of i nt erf ace conf i gurat i on](/views2/1206859/page18/bg12.png)
Command Line Interface Reference Manual
18
interface. The sub-interface derived from physical interface. Please see Introduction of sub-interface for more
details. The logic interface indicates the interface that created manually by user and without corresponding
physical equipment.
Presently, the physical interfaces supported by D-Link Router that include:
• Ethernet
• FastEthernet
• Synchronous Serial
• Low-speed Serial
• Asynchronous Serial
• Channelized E1
• ISDN PRI interface
• ISDN BRI interface
• DTU interface
• Asynchronous MODEM interface
Presently, the logic interface supported by D-Link Router are:
• Loop-back interface
• Empty interface
• Dialup interface
• Virtual template and virtual access interface
• Tunnel interface
• Sub-interface
３．２ Ｉｎｔｒｏｄｕｃｔｉｏｎ ｏｆ Ｉｎｔｅｒｆａｃｅ Ｃｏｎｆｉｇｕｒａｔｉｏｎ
These following instructions apply to all interface configuration processes. Users should begin interface configuration in
global configuration mode and follow these steps:
1. Use the command “interface” to begin to configure the related interface parameters. User can use command “show
interface” to display the interface. All the interfaces of the device will provide theirs status as follows:
[DEFAULT@4_2750 /enable/]#show
(00)alias alias for command
......
(19)interface interface status and configuration
......
Please Input the code of command to be excute(0-45): 19
Input 17，choose “interface”，it will prompt：
(00)FastEthernet FastEthernet interface
(01)Ethernet Ethernet interface
(02)Serial Serial interface
(03)Async Asynchronous interface
(04)Null Null interface
Please Input the code of command to be excute(0-4): 2
Input 2，choose “Serial”，the prompt will be：
Please input a interface name:s1/0
Input the value of type、slot and port of the interface，it will display：
Serial 1/0 is administratively down, line protocol is down
Hardware is SCC Mode=Sync,Speed=64000
DTR=UP,DSR=DOWN,RTS=DOWN,CTS=DOWN,DCD=DOWN
MTU 1500 bytes, BW 64 kbit, DLY 20000 usec
Encapsulation HDLC, loopback not set
Keepalive set(10 sec)
