Command Line Interface Reference Manual
12
WIC，FIC slot modules or interface cards, please refer to Hardware Description.
１．３ Ｂｅｆｏｒｅ Ｓｔａｒｔ
Please confirm the following steps before power on the router for configuration:
Step 1. Set up Router’s hardware according to the requirement of User Manual
Step 2. Configure the PC terminal emulation program
Step 3. For Internet Protocol (IP), decide:
· Layout of IP addresses
· Which WAN (Wide Area Network) protocols (egg. Frame Relay、HDLC、X.25) are to be used on
each port
１．４ Ｇｅｔ Ｈｅｌｐ
ls command and its -1 option can help to input the commands:
· Type in 1s command to display the list of currently available commands
[DEFAULT@Router /]#ls
· Type in ls –l command to display the list of currently available commands and the brief introduction
[DEFAULT@Router /]#ls -l
· Press Up direction key to display the formerly input commands. To display more commands please continue to
press the Up key.
１．５ Ｃｏｍｍａｎｄ Ｄｉｒｅｃｔｏｒｙ
The Router user interface includes various directories, each of them enable you to configure different components on the
Router. The currently available command relies on the location of your command directory. Type in the 1s command to
display the available command list under each command directory. The following table lists the frequently used
commands:
Command
Directory
Entry Method Interface Promote Quit Method
System Monitor
Directory
Power on the device and input
“”Ctrl+Break
monitor# By quit command
User Directory Log in [DEFAULT@Router/]# By exit or quit command
Management
Directory
Input “cd enable” command under
the User Directory
[DEFAULT@Router#enabl
e/]#
By cd.. command
Global
Configuration
Directory
Input “cd config” command under
the Management Directory
[DEFAULT@Router/config
/]#
Use cd.. command to
return to the
Management Directory
Each command directory has a limit to use the subset of commands. If you have a problem when inputting the command,
please check the prompt and input 1s command to obtain available commands list.
Please notify the new command directory that displayed by the change of interface prompt in the following example：
[DEFAULT@Router/]# cd enable
Password: <enter password>
[DEFAULT@Router/enable/]# cd config
[DEFAULT@Router/config/]# cd ..
[DEFAULT@Router/enable/]# cd ..
[DEFAULT@Router/]#
１．６ Ｃａｎｃｅｌ Ａ Ｃｏｍｍａｎｄ
If you want to cancel a command or restore it to default properties, you can select U or u option at prompt rightly after
inputting most of the commands.
