Command Line Interface Reference Manual
488
Ｔａｋｅ ｔｈｅ １
ｓｔ
ｃｏｍｍａｎｄ ａｓ ａｎ ｅｘａｍｐｌｅ
Ｓｅｌｅｃｔ ２８ ｉｔｅｍ ｆｒｏｍ ｌｉｓｔｉｎｇ， ｄｉｓｐｌａｙ：
(00)K The size of the sending window
(01)N1 Max number of bytes for incoming frames
(02)N2 Number of retry times
......
Please Input the code of command to be excute(0-16): 1
Input 1，select 1item ，display：
(00)<1-1500> Max number of bytes for incoming frames
Please Input the code of command to be excute(0-0): 0
Select 0，and input bit-count。
10.3.6 Control the Buffer Size
You can control the buffer size on the router. The buffer holds data that is pending transmission to a remote SDLC station.
This command is particularly useful in the case of the SDLLC media translator, which allows an LLC2-speaking SNA
station on a Token Ring to communicate with an SDLC-speaking SNA station on a serial link. The frame sizes and
window sizes on Token Rings are often much larger than those acceptable for serial links, and serial links are often slower
than Token Rings.
To control backlogs that can occur during periods of high data transfer from the Token Ring to the serial line, use the
following command in interface configuration mode on a per-address basis:
Ｃｏｍｍａｎｄ Ｐｕｒｐｏｓｅ
ｓｄｌｃ ｈｏｌｄｑｕｅｕｅ ａｄｄｒｅｓｓ ｑｕｅｕｅ－ｓｉｚｅ
Set the maximum number of packets held in
queue before transmitting.
Select 28 item from listing, display:
（００）Ｋ Ｔｈｅ ｓｉｚｅ ｏｆ ｔｈｅ ｓｅｎｄｉｎｇ ｗｉｎｄｏｗ
．．．．．．
（０５）ｈｏｌｄｑｕｅｕｅ ｔｈｅ ｍａｘ ｑｕｅｕｅ ｌｅｎｇｔｈ
．．．．．．
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１６）： ５
Ｉｎｐｕｔ ５，ｓｅｌｅｃｔ ｈｏｌｄｑｕｅｕｅ ｉｔｅｍ ，ｄｉｓｐｌａｙ：
（００）＜１－ＦＥ＞ ＳＤＬＣ Ａｄｄｒｅｓｓ ｉｎ Ｈｅｘ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－０）： ０
Ｉｎｐｕｔ ０，ｄｉｓｐｌａｙ：
Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｄｉｇｉｔａｌ ｎｕｍｂｅｒ：Ｐｌｅａｓｅ ｉｎｐｕｔ ａ ｓｔｒｉｎｇ：
Ｉｎｐｕｔ ａｄｄｒｅｓｓ，ｄｉｓｐｌａｙ：
（００）＜０－６５５３５＞ Ｑｕｅｕｅ ｓｉｚｅ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－０）： ０
Ｓｅｌｅｃｔ ０，ａｎｄ ｉｎｐｕｔ ｑｕｅｕｅ－ｓｉｚｅ。
sdlc n1 bit-count
Set the maximum size of an
incoming frame.
sdlc k window-size
Set the local window size of the
router.
sdlc poll-limit-value count
Set how many times a primary
station will poll a secondary
station.
