Command Line Interface Reference Manual
105
4.4.11 X.3 Profile Example
The following example modifies and loads an existing X.25 PAD parameter profile. It accesses the existing PAD profile
ppp, changes its padding parameter (specified as 9) to a value of 2, and displays the new parameters using the par
command in PAD mode.
［ＤＥＦＡＵＬＴ＠ＲｏｕｔｅｒＡ ／ｅｎａｂｌｅ／］＃ ｐａｄ ３３３３
［ＤＥＦＡＵＬＴ＠ＲｏｕｔｅｒＢ ／］＃ ｃｔｒｌ－ｐ
ｐａｄ＞ｐｒｏｆ ０
ｐａｄ＞ｐａｒ
ＰＡＲ １：１ ２：１ ３：１２６ ４：０ ５：１ ６：２ ７：２ ８：０ ９：２ １０：０ １１：１４ １２：１ １３：０ １４：０ １５：０ １６：１２７ １７：２４ １８：１８ １９：２ ２０：０
２１：０ ２２：０
Note: If the X.29 profile is set to default, the profile is applied to all incoming X.25 PAD calls, including the calls used for
protocol translation.
4.4.12 Getting Help Example
Use the help command to get short descriptions of the available parameters.
pad> help
CLR - clear X.25 connection
HELP - this help
INT - send interrupt packet over X.25 connection
PAR? - show X.3 parameters as wanted
PROF - use X.3 profile 0 or 1
QUIT - quit PAD and clear connection
RESET - send RESET packet over X.25 connection
SET - set X.3 parameters
SET? - set X.3 parameters and show it
STAT - show X.25 connection status
4.4.13 Monitoring X.25 Network Example
Following is show x25 command output example:
［ＤＥＦＡＵＬＴ＠ＲｏｕｔｅｒＡ ／ｅｎａｂｌｅ／］＃ ｐａｄ ｓｖｃ １２３４５６７８９
ＣＯＭ
［ＤＥＦＡＵＬＴ＠ＲｏｕｔｅｒＢ ／］＃ ｅｎｔ
［ＤＥＦＡＵＬＴ＠ＲｏｕｔｅＢ ／ｅｎａｂｌｅ／］＃ｓｈｏｗ ｘ２５
Ｘ．２５／ＩＰ ｓｔａｔｅ
Ｓｅｒｉａｌ１／０＝ＵＰ
＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝
Ｎｏ．Ｐｏｒｔ ＶＣ Ｉ／Ｏ Ｓｔａｔｅ Ｘ．１２１ａｄｄｒ ＩＰａｄｄｒ ｈｏｓｔｎａｍｅ
＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝
０１ Ｓｅｒｉａｌ１／０ １６ ｉｎ ｗｏｒｋ １１１１
［ＤＥＦＡＵＬＴ＠ＲｏｕｔｅｒＢ ／ｅｎａｂｌｅ／］＃
4.5 Configuring PPP Task List
This section describes how to configure the Point-to-Point Protocol(PPP).(PPP).This section also describe the address
pool responding point-to-point connection that apply to asynchronous serial, synchronous serial and ISDN interface.
For complete description of PPP command, refer to “PPP Command Reference” chapter.
