Command Line Interface Reference Manual
94
5、Debug the LAPB frames
[DEFAULT@Router /enable/]#debug
……
(14)l2tp L2TP information
(15)lapb LAPB information
……
Please Input the code of command to be excute(0-27): 15
(00)iframes LAPB I frames
(01)raw LAPB raw frames content
(02)sframes LAPB S frames
(03)uframes LAPB U frames
Please Input the code of command to be excute(0-3): 00
(00)interface-name
(01)<cr>
Please Input the code of command to be excute(0-1): 00
Please input a interface name:s0/1 （input interface name）
Will you excute it? (Y/N):y
6、Debug the x25 internal events and datagram
[DEFAULT@Router /enable/]#debug
……
(26)tunnel Generic Tunnel Interface
(27)x25 X.25 information
Please Input the code of command to be excute(0-27): 27
(00)events All non-data packets
(01)normal All data packets
(02)packet raw packets
(03)tcp Debug X25-TCP
(04)xot Debug XOT(X.25-Over-TCP) packet
Please Input the code of command to be excute(0-4): 00
(00)interface-name
(01)<cr>
Please Input the code of command to be excute(0-1): 00
Please input a interface name:s0/1 （input interface name）
Will you excute it? (Y/N):y
7、Debug the setup process of xot
[DEFAULT@Router /enable/]#debug
……
(26)tunnel Generic Tunnel Interface
(27)x25 X.25 information
Please Input the code of command to be excute(0-27): 27
(00)events All non-data packets
(01)normal All data packets
(02)packet raw packets
(03)tcp Debug X25-TCP
(04)xot Debug XOT(X.25-Over-TCP) packet
Please Input the code of command to be excute(0-4): 4
(00)<cr>
Please Input the code of command to be excute(0-0): 00
Will you excute it? (Y/N):y
