Command Line Interface Reference Manual
291
wanted RSVP, RSVP will function on these interfaces.
To enable RSVP on an interface, perform the following task in global configuration mode:
Command Purpose
ip rsvp bandwidth [interface-kbps] [single-flow-kbps] Configure RSVP on network interface.
Ｉｎ ｔｈｅ ｐｒｏｍｐｔ Ｓｅｌｅｃｔ ｉｐ ｏｐｔｉｏｎ ，ｔｈｅｎ ｐｒｏｍｐｔ ｉｓ ａｓ ｂｅｌｏｗ：
（００）ａｃｃｅｓｓ－ｇｒｏｕｐ Ｓｐｅｃｉｆｙ ａｃｃｅｓｓ ｃｏｎｔｒｏｌ ｆｏｒ ｐａｃｋｅｔｓ
．．．．．．
（１４）ｒｓｖｐ ＲＳＶＰ ｉｎｔｅｒｆａｃｅ ｃｏｍｍａｎｄ
．．．．．．
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－１８）： １４
ｉｎｐｕｔ １４，Ｓｅｌｅｃｔ ｒｓｖｐ ｏｐｔｉｏｎ ，ｐｒｏｍｐｔ ｉｓ ａｓ ｂｅｌｏｗ：
（００）ｂａｎｄｗｉｄｔｈ ＲＳＶＰ ｉｎｔｅｒｆａｃｅ ｂａｎｄｗｉｄｔｈ ｓｅｔｔｉｎｇ
（０１）ｔｏｓ ＲＳＶＰ ＴＯＳ ｓｅｔｔｉｎｇ
（０２）ｐｒｅｃｅｄｅｎｃｅ ＲＳＶＰ ｐｒｅｃｅｄｅｎｃｅ ｓｅｔｔｉｎｇ
（０３）ｎｅｉｇｈｂｏｒ ＲＳＶＰ ｎｅｉｇｈｂｏｒ ｓｅｔｔｉｎｇ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－３）： ０
ｉｎｐｕｔ ０，Ｓｅｌｅｃｔ ｂａｎｄｗｉｄｔｈ ｏｐｔｉｏｎ ，ｐｒｏｍｐｔ ｉｓ ａｓ ｂｅｌｏｗ：
（００）＜１－１００００００＞ Ａｍｏｕｎｔ ｏｆ ｂａｎｄｗｉｄｔｈ （ｉｎ ｋｂｐｓ） ｏｎ ｉｎｔｅｒｆａｃｅ ｔｏ ｂｅ ｒｅｓｅｒｖｅｄ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－０）： ０
ｉｎｐｕｔ ０， ａｎｄ ｃｏｎｆｉｒｍ ｉｔinterface-kbps ｖａｌｕｅ ，ｐｒｏｍｐｔ ｉｓ ａｓ ｂｅｌｏｗ：
（００）＜１－１００００００＞ Ａｍｏｕｎｔ ｏｆ ｂａｎｄｗｉｄｔｈ （ｉｎ ｋｂｐｓ） ａｌｌｏｃａｔｅｄ ｔｏ ａ ｓｉｎｇｌｅ ｆｌｏｗ
Ｐｌｅａｓｅ Ｉｎｐｕｔ ｔｈｅ ｃｏｄｅ ｏｆ ｃｏｍｍａｎｄ ｔｏ ｂｅ ｅｘｃｕｔｅ（０－０）： ０
ｉｎｐｕｔ ０， ａｎｄ ｃｏｎｆｉｒｍ ｉｔsingle-flow-kbps ｖａｌｕｅ ．
Ｎｏｔｅ： Ｗｈｅｎ ｕｓｉｎｇ ｉｐ ｒｓｖｐ ｂａｎｄｗｉｄｔｈ ｃｏｍｍａｎｄ， ｉｆ ｉｎｔｅｒｆａｃｅ－ｋｂｐｓ ａｎｄ ｓｉｎｇｌｅ－ｆｌｏｗ－ｋｂｐ ａｒｅ ｏｍｉｔｔｅｄ， ｔｈｅ
ｗｈｏｌｅ ｐｏｒｔ ｃａｎ ａｐｐｌｙ ｆｏｒ ｕｐｐｅｒ ｌｉｍｉｔ ｏｆ ｒｅｓｅｒｖａｔｉｏｎ ｒｅｓｏｕｒｃｅ， ａｎｄ ｓｉｎｇｌｅ ｄａｔａ ｆｌｏｗ ｃａｎ ａｐｐｌｙ ｆｏｒ ａｎ
ｕｐｐｅｒ ｌｉｍｉｔ ｏｆ ｒｅｓｅｒｖａｔｉｏｎ ｒｅｓｏｕｒｃｅ ｗｈｉｃｈ ｉｓ ７５％ ｏｆ ｐｏｒｔ ｒｅｓｏｕｒｃｅ ｂｙ ｄｅｆａｕｌｔ．
5.11.2 How to Enable RSVP in IP Phone Module
Before configuring D-LINK IP Phone and D-LINK IP Phone module as well as use Voice over IP, user must enable RSVP
in command to configure resource reservation for voice flow with RSVP:
Do configure RSVP commands on the port needing RSVP configuration because RSVP is disabled on port by default.
(Refer to last section for usage.)
Because IP Phone disables QOS by default, user should enable QOS in dial-peer voip.
Use command below in dail-peer configuration state to enable RSVP on port f0/0:
Command Purpose
req－qos｛guarantee | load｝〔 flow－kbps〕
Configure bandwidth for IP Phone voice flow.
Ｎｏｔｅ： Ｉｎ ｔｈｅ ｄｅｆａｕｌｔ ｏｆ ｇｕａｒａｎｔｅｅ ｜ ｌｏａｄ， ｒｅｓｏｕｒｃｅ ｒｅｓｅｒｖａｔｉｏｎ ｆｏｒｍ ｉｓ ｇｕａｒａｎｔｅｅ． Ｉｎ ｔｈｅ ｄｅｆａｕｌｔ ｏｆ
ｆｌｏｗ－ｋｂｐｓ， ｒｅｓｅｒｖａｔｉｏｎ ｂａｎｄｗｉｄｔｈ ｉｓ ２４ｋｂｐｓ．
5.11.3 Use RSVP Assistant Configuration Commands
On RSVP module implementation of current edition, user can process RSVP debug with assistant configuration
commands, including setting up of RSVP session and transmitting information of RSVP path, path tear, resv, resv tear,
offered by the module. This will affect very much on RSVP debug.
