Command Line Interface Reference Manual
336
Following table lists the supported login authentication methods:
Keyword Description
enable Use enable password for authentication
group Use server group for authentication
group-restrict
Uses the list of all servers for authentication, but when using the specified server,
the group will be invalid.
line Uses the line password for authentication.
none Uses no authentication.
radius Uses RADIUS authentication.
tacacs+ Uses TACACS+ authentication.
When configured enable authentication method as the remote authentication (i.e. configured group,
group-restrict, radius or tacacs+ as the keywords), the usernames that respectively use RADIUS and
TACACS+ to authenticate are different, the following is the introduction for each type:
l Ｕｓｅ ＲＡＤＩＵＳ ｔｏ ｐｒｏｃｅｅｄ ｅｎａｂｌｅ ａｕｔｈｅｎｔｉｃａｔｉｏｎ：
Ｔｈｅ ａｕｔｈｅｎｔｉｃａｔｅｄ ｕｓｅｒｎａｍｅ ｉｓ $ENABLElevel$， ｉｎ ｗｈｉｃｈ leve ｉｎｄｉｃａｔｅｓ ｔｈｅ ｐｒｉｖｉｌｅｇｅ ｌｅｖｅｌ ｔｈａｔ ｔｈｅ ｕｓｅｒ ｉｓ
ｔｏ ｅｎｔｅｒ， ｉ．ｅ． ｔｈｅ ｎｕｍｂｅｒ ｔｈａｔ ｉｍｐｌｉｅｓ ｔｈｅ ｐｒｉｖｉｌｅｇｅ ｎｕｍｂｅｒ ｂｅｈｉｎｄ ｅｎａｂｌｅ ｃｏｍｍａｎｄ． Ｆｏｒ ｉｎｓｔａｎｃｅ， ｉｆ ｙｏｕ
ａｒｅ ｔｏ ｅｎｔｅｒ ａ ｐｒｉｖｉｌｅｇｅ ｌｅｖｅｌ ７， ｙｏｕ ｎｅｅｄｓ ｔｏ ｉｎｐｕｔ ｃｏｍｍａｎｄ ｅｎａｂｌｅ ７． Ｉｎ ｔｈｉｓ ｃａｓｅ， ｉｆ ｙｏｕ ｈａｓ ｃｏｎｆｉｇｕｒｅｄ
ｔｏ ｕｓｅ ＲＡＤＩＵＳ ｆｏｒ ａｕｔｈｅｎｔｉｃａｔｉｏｎ， ｔｈｅｎ ｔｈｅ ｕｓｅｒｎａｍｅ ｓｕｂｍｉｔｔｅｄ ｔｏ Ｒａｄｉｕｓ ｓｅｒｖｅｒ ｉｓ ￥ＥＮＡＢＬＥ１５￥， ｔｈｕｓ ｎｅｅｄ ｔｏ
ｃｏｎｆｉｇｕｒｅ ｒａｌａｔｉｎｇ ｕｓｅｒｎａｍｅ ａｎｄ ｐａｓｓｗｏｒｄ ｏｎ Ｒａｄｉｕｓ ｓｅｒｖｅｒ ｉｎ ａｄｖａｎｃｅ． Ｉｔ ｉｓ ｅｓｐｅｃｉａｌｌｙ ｐｏｉｎｔｅｄ ｏｕｔ ｔｈａｔ
ｙｏｕ ｎｅｅｄ ｔｏ ｃｌａｒｉｆｙ ｔｈａｔ ｔｈｅ ｓｅｒｖｉｃｅ ｔｙｐｅ ｕｓｅｄ ｆｏｒ ｐｒｉｖｉｌｅｇｅ ａｕｔｈｅｎｔｉｃａｔｉｏｎ ｉｎ ｔｈｅ Ｒａｄｉｕｓ Ｓｅｒｖｅｒ ｕｓｅｒ ｄａｔａｂａｓｅ
ｉｓ ６， ｉ．ｅ． Ａｄｍｉｎ－Ｕｓｅｒ ．
l Ｕｓｅ TACACS+ ｔｏ ｐｒｏｃｅｅｄ ａｕｔｈｅｎｔｉｃａｔｉｏｎ
Ｔｈｅ ｕｓｅｒｎａｍｅ ｕｓｅｄ ｆｏｒ ｅｎａｂｌｅ ａｕｔｈｅｎｔｉｃａｔｉｏｎ ｉｓ ｔｈｅ ｏｎｅ ｔｈａｔ ｕｓｅｄ ｗｈｅｎ ｔｈｉｓ ｕｓｅｒ ｌｏｇｉｎ ｔｈｅ Ｒｏｕｔｅｒ． Ｆｏｒ ｅｘａｍｐｌｅ，
ｉｆ ａ ｕｓｅｒ ｔｙｐｅｄ ｃｈｅｎ ｆｏｒ ｕｓｅｒｎａｍｅ ｗｈｅｎ ｌｏｇｉｎ ｉｎ ｔｈｅ Ｒｏｕｔｅｒ， ｔｈｅ ｕｓｅｒｎａｍｅ ｕｓｅｄ ｆｏｒ ｅｎａｂｌｅ ａｕｔｈｅｎｔｉｃａｔｉｏｎ ｓｈｏｕｌｄ
ｂｅ ｃｈｅｎ ｔｏｏ． Ｉｆ ｔｈｅ ｕｓｅｒ ｉｓ ｎｏｔ ｒｅｑｕｉｒｅｄ ｔｏ ｐａｓｓ ａｕｔｈｅｎｔｉｃａｔｉｏｎ ｏｒ ｉｓ ｎｏｔ ｉｎｄｉｃａｔｅｄ ｔｏ ｉｎｐｕｔ ｔｈｅ ｕｓｅｒｎａｍｅ
ｗｈｅｎ ｐｒｏｃｅｅｄｉｎｇ ｔｈｅ ａｕｔｈｅｎｔｉｃａｔｉｏｎ， ｔｈｅ ｕｓｅｒｎａｍｅ ａｆｔｅｒ ｓｕｃｃｅｓｓｆｕｌ ｌｏｇｉｎ ｓｈｏｕｌｄ ｂｅ ＤＥＦＡＵＬＴ， ａｎｄ ｙｏｕ ｎｅｅｄ ｔｏ
ｓｅｔ ｕｐ ｉｎ ｔｈｅ ｕｓｅｒ ｄａｔａｂａｓｅ ｏｆ TACACS+ Server．
6.1.2.3.4 Change The String To Prompt Inputting The Password
Use aaa authentication password-prompt command to change the default text that the D-Link router displays when
prompting a user to enter a password. This command changes the password prompt for the enable password as well as for
login passwords that are not supplied by remote security servers. The undo form of this command restores the password
prompt to the following default value:
Password：
aaa authentication password-prompt command does not change any prompt message provided by a remote TACACS+
server or RADIUS server. Use the following command in global configuration directory:
Command Purpose
aaa authentication password-prompt text-string
Change the default text displayed when a user
is prompted to enter a password.
Example:
[DEFAULT@Router /config/]#aaa
(00)accounting Accounting configurations parameters
(01)authentication Authentication configurations parameters
