Command Line Interface Reference Manual
72
Key Word:
Q(quit)
……
(02)Serial Serial interface
(03)Async Asynchronous interface
Please Input the code of command to be excute(0-3): 2
Please input a interface name:s1/0 （input the interface name）
Will you excute it? (Y/N):y
If you want to show the message of frame-relay mapping or switching :
[DEFAULT@Router /config/]#show
Key Word:
U(undo) D(default) Q(quit)
……
(16)frame-relay Display Frame Relay state
(17)frswitch Display Frame Relay switch state
……
Please Input the code of command to be excute(0-49): 16 （you can also choose 17 to show也可选 the frame-relay switch）
Will you excute it? (Y/N):y
4.2.23 Frame Relay Configuration Examples
This section provides examples of Frame Relay configurations. It includes the following sections:
4.2.24 Encapsulation Examples
The first example that follows sets Frame Relay encapsulation at the interface.
encapsulation frame-relay
frame-relay map 131.108.123.2 pvc 48
frame-relay map 131.108.123.3 pvc 49 broadcast
4.2.25 Static Address Mapping Examples
The following sections provide examples of how to configure static mapping.
Router 1
interface s1/0
ip address 131.108.64.2 255.255.255.0
encapsulation frame-relay
frame-relay intf-type dce
frame-relay local_dlci 43
frame-relay map 131.108.64.1 pvc 43
Router 2
interface s1/0
ip address 131.108.64.1 255.255.255.0
encapsulation frame-relay
frame-relay map 131.108.64.2 pvc 43
4.2.26 Frame Relay Switching Examples
The following sections provide several examples of configuring one or more routers as Frame Relay switches:
PVC Switching Configuration Example
-- In this example, one router has two interfaces configured as DCEs; the router switches frames from the incoming
